Parker 690-433156F2-B00P00-A400 690+ AC Variable Frequency Drive

Product Description

The 690-433156F2-B00P00-A400 is a Parker SSD 690+ series AC variable frequency drive, designed for three-phase motor speed regulation. It adopts vector control algorithm, supports open-loop and closed-loop control, with built-in PID, multi-speed and ramp function. This specific ordering code defines power rating, voltage class, keypad, option modules and enclosure. It is widely used for fan, pump, conveyor and process motor control, and is commonly used as spare parts for legacy industrial automation systems.

Features

• Vector control VFD, supports open-loop and encoder feedback closed-loop control
• Integrated PID regulator for pressure, flow and temperature closed-loop control
• Built-in multi-speed preset, adjustable acceleration / deceleration ramps
• Rich protection: overcurrent, overvoltage, undervoltage, overheat, motor overload, phase loss
• Supports serial communication options including Modbus RTU, Profibus, DeviceNet
• Front panel keypad for local parameter setup, monitoring and manual operation
• Compact panel mount design, robust for continuous heavy-duty industrial operation
• Compatible with 690+ software for PC commissioning, parameter backup and diagnostics

Application Scenarios

• Water treatment pump and fan energy-saving speed regulation
• Conveyor, mixer, extruder and packaging machine motor control
• Textile, printing and metal processing production line drive systems
• Legacy Parker SSD 690+ cabinet overhaul and spare parts replacement
• Process plant auxiliary motor variable speed control projects

FAQ

Q: What series is this drive?
A: It belongs to Parker SSD 690+ variable frequency drive series.

Q: What control modes does it support?
A: Open-loop vector, closed-loop vector with encoder feedback and V/F control.

Q: Is this series still in active production?
A: The 690+ series is obsolete, mainly supplied as surplus stock and refurbished spare parts.

Q: What software is used for configuration?
A: Parker DSELite software for parameter setting, monitoring and fault diagnosis.
