Enterasys A2H254-16 P0973BK | SecureStack A2 16-Port Ethernet Switch
8×100BASE-TX + 8×100BASE-FX + 2×SFP Uplinks for Industrial Automation, DCS/PLC Integration, and Enterprise SecureStack Deployments
1. Product Overview
The Enterasys A2H254-16 P0973BK is a 16-port managed Ethernet switch from the SecureStack A2 series, optimized for industrial automation and enterprise network deployments requiring mixed copper/fiber connectivity, high availability, and centralized management. It features 8×100BASE-TX RJ45 copper ports, 8×100BASE-FX multi-mode MT-RJ fiber ports, and 2×SFP uplink slots for 1000BASE-T/1000BASE-SX/LX connectivity, delivering a 48Gbps switching capacity and 35.7Mpps forwarding rate for low-latency data exchange in DCS, PLC, and SCADA systems. The switch supports SecureStack stacking (up to 8 units), VLAN (4K), QoS (802.1p), link aggregation (LACP), and ACL security, with redundant power options and fanless design for harsh industrial sites. With a 100-240V AC power supply, operating temperature range of 0°C to +40°C, and compliance with IEEE 802.3, 802.1Q, and UL 508 standards, it ensures reliable performance in industrial control networks, manufacturing floors, data centers, and enterprise access layers, serving as a scalable, secure, and easy-to-manage solution for seamless integration with Foxboro DCS and third-party automation equipment.
Key Specifications
• Model: A2H254-16 P0973BK | SecureStack A2 16-Port Managed Ethernet Switch
• Port Configuration: 8×100BASE-TX (RJ45, 10/100 Mbps); 8×100BASE-FX (MT-RJ, multi-mode fiber); 2×SFP (Mini-GBIC) uplink slots (1000BASE-T/SX/LX compatible)
• Performance: Switching Capacity: 48Gbps; Forwarding Rate: 35.7Mpps; MAC Address Table: 8K; Jumbo Frame Support (up to 9KB)
• Stacking: SecureStack A2 Stackable (up to 8 units, 140.8Gbps backplane)
• Management: Web GUI, CLI (SSH/Telnet), SNMP v1/v2c/v3; RMON for traffic monitoring
• Features: VLAN (4K, 802.1Q); QoS (802.1p, DSCP); LACP (802.3ad); ACLs; Port Security; Auto-sensing (speed/duplex)
• Power Supply: AC 100-240V ±10%, 50/60Hz; Redundant power input support; Typical power consumption: 18W
• Environmental: Operating Temperature: 0°C to +40°C (+32°F to +104°F); Storage: -40°C to +85°C (-40°F to +185°F); Humidity: 10% to 90% (Non-condensing)
• Dimensions: 44mm × 210mm × 300mm (1.7" × 8.3" × 11.8"); Net Weight: 1.08 kg
• Certifications: CE, UL 508, IEEE 802.3/802.3u/802.1Q/802.1p, RoHS
2. Core Features
• Mixed Copper/Fiber Connectivity: 8×RJ45 + 8×MT-RJ ports for flexible industrial I/O/controller connections; 2×SFP uplinks for long-distance/ high-speed backbone integration.
• SecureStack Stacking: Up to 8 units in a single stack for centralized management and 140.8Gbps backplane scalability.
• Enterprise-Grade Security: ACLs, port security, and SNMP v3 for protection against unauthorized access and data breaches.
• QoS for Critical Traffic: Prioritizes DCS/PLC/SCADA data with 802.1p and DSCP marking, ensuring real-time control performance.
• Redundant Power: Dual power inputs for fault tolerance in industrial control networks.
• Fanless Design: No moving parts for reduced maintenance and improved reliability in harsh environments.
• Auto-Sensing Ports: Automatically detects speed/duplex settings for plug-and-play device integration.
• Comprehensive Management: Web GUI/CLI/SNMP for easy configuration; RMON for proactive traffic monitoring and troubleshooting.
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
Sales Manager: KI MI
WeChat: 18059884790
Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.
3. Typical Applications
• Industrial Automation: DCS/PLC network integration (Foxboro I/A Series, Invensys); Robot cell connectivity; SCADA-to-field device data routing.
• Oil & Gas: Offshore platform control networks; Pipeline monitoring systems; Fiber-optic backhaul for remote wellheads.
• Manufacturing: Factory floor access layer switching; Machine-to-machine (M2M) communication; Quality control system integration.
• Data Centers: Server farm access; Storage area network (SAN) connectivity; Redundant uplink aggregation.
• Enterprise Networks: Campus LAN access; Remote office connectivity; SecureStack backbone extension for multi-building deployments.
4. Installation & Maintenance
Installation: 1U rack-mount; Connect power (redundant recommended); Wire copper/fiber ports to devices; Insert SFP modules for uplinks; Stack (if needed) with SecureStack cables.
Configuration: Access via Web GUI/CLI; Set IP address; Configure VLANs/QoS/ACLs; Enable stacking (if used); Set up port security and SNMP.
Maintenance: Weekly: Check status LEDs (Power, Stack, Link/Activity, Fault). Monthly: Inspect power connections and SFP modules; Verify stack synchronization. Annual: Update firmware; Clean dust filters; Test redundant power switchover.
Fault Diagnosis: No uplink: Check SFP module compatibility and fiber polarity. Stack issues: Verify stack cables and master/slave configuration. Port errors: Check cable quality and auto-sensing settings; Use RMON to identify traffic anomalies.
Technical Document | Enterasys A2H254-16 P0973BK | SecureStack A2 16-Port Managed Ethernet Switch for Industrial & Enterprise Networks
