CTI 2500-RBC 901E-2500-RBC | Profibus Remote Base Controller-KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

CTI 2500-RBC 901E-2500-RBC | Profibus Remote Base Controller

PROFIBUS DP Slave Node for CTI 2500/Simatic 505 I/O Bases - Direct Replacement for Siemens 505-6870, 9.6 Kbaud to 12 Mbaud Speeds, GSD File Support

1. Product Overview

The CTI 2500-RBC 901E-2500-RBC is a Profibus Remote Base Controller (RBC) that allows CTI 2500 Series or Simatic 505 I/O bases to operate as slave nodes on a PROFIBUS DP network, designed as a direct replacement for Siemens 505-6870 RBCs in industrial automation systems. It supports Profibus communication speeds from 9.6 Kbaud (1200m max cable distance) to 12 Mbaud (100m max cable distance), compatible with Siemens S5/S7 and other Profibus masters, and works with 4/8/16-slot CTI/Siemens I/O bases, supporting all discrete/analog I/O modules. The module includes a GSD file for easy configuration, LED display for error codes/station addresses, and operates on 5V DC (from I/O base backplane), with an operating temperature range of 0°C to +60°C, ensuring reliable I/O data exchange in manufacturing, oil & gas, and process control applications, ideal for upgrading legacy systems to Profibus DP without replacing existing I/O infrastructure.

CTI 2500-RBC 901E-2500-RBC (1).png

Key Specifications

• Model: 2500-RBC (901E-2500-RBC) | Profibus Remote Base Controller

• Function: Enables CTI 2500/Simatic 505 I/O bases as PROFIBUS DP slave nodes

• Compatibility: Siemens S5/S7, CTI 2500 Series, Simatic 505; replaces Siemens 505-6870

• I/O Base Support: 4/8/16-slot CTI/Siemens bases; all discrete/analog I/O modules

• Profibus DP: 9.6 Kbaud to 12 Mbaud (1200m to 100m max distance per segment)

• Configuration: GSD file included for Profibus configurators; LED display (error codes/station address)

• Power: 5V DC from I/O base backplane; no external power required

• Environmental: Operating Temperature: 0°C to +60°C (+32°F to +140°F); Storage: -40°C to +85°C (-40°F to +185°F); Humidity: 5% to 95% (Non-condensing)

• Dimensions: 120mm × 30mm × 160mm (4.7" × 1.2" × 6.3"); Net Weight: 0.3 kg

• Certifications: PROFIBUS DP compliant, CE, RoHS

CTI 2500-RBC 901E-2500-RBC (3).png

2. Core Features

• Direct Replacement: Drop-in for Siemens 505-6870 RBCs in legacy systems

• Wide Compatibility: Works with Siemens S5/S7, CTI 2500, Simatic 505, and other Profibus masters

• Flexible Speeds: 9.6 Kbaud to 12 Mbaud with distance scaling for industrial networks

• Full I/O Support: All discrete/analog modules in 4/8/16-slot CTI/Siemens bases

• Easy Configuration: GSD file for quick setup in PROFIBUS networks

• Diagnostics: LED display for error codes and station address; no PLC programming over serial port

• Backplane Power: 5V DC from I/O base; no external power needed

• Rugged Design: Industrial temperature range (0°C to +60°C) for harsh environments

CTI 2500-RBC 901E-2500-RBC (6).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Industrial Automation: Legacy CTI 2500/Simatic 505 I/O integration into Profibus DP networks; factory floor I/O expansion

• Oil & Gas: Remote wellhead monitoring; pipeline control systems; refinery process I/O networks

• Manufacturing: Automotive assembly lines; packaging machinery I/O; food/beverage processing control

• Water/Wastewater: Pump station I/O monitoring; treatment plant control systems

• Power Generation: Auxiliary system I/O; turbine control network integration

CTI 2500-RBC 901E-2500-RBC (5).png

4. Installation & Maintenance

Installation: Insert into CTI 2500/Simatic 505 I/O base slot; connect Profibus DP cable to port; power via backplane.

Configuration: Load GSD file into Profibus configurator; set station address (via DIP switches); match baud rate with master.

Maintenance: Weekly: Check LED status (Power, Profibus Communication, Error). Monthly: Inspect Profibus cable connections; verify station address settings. Annual: Clean module vents; test I/O module communication.

Fault Diagnosis: No communication: Check Profibus cable polarity/termination; verify baud rate. Error LED: Use GSD file diagnostics; check I/O module compatibility. No I/O data: Confirm station address; test I/O base backplane power.

Technical Document | CTI 2500-RBC 901E-2500-RBC | Profibus Remote Base Controller for CTI 2500/Simatic 505 I/O Bases
