Socapel Socasin ST110-310 AC Servo Drive--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

Socapel Socasin ST110-310 AC Servo Drive

Digital 3-Phase Sinusoidal Servo Amplifier | Komax Alpha 411 Integration | Precision Motion Control for Industrial Automation

1. Core Product Overview

The Socapel ST110-310 (Socasin ST1 series) is a digital 3-phase AC servo drive designed for precision motion control in industrial automation, optimized for Komax Alpha 411 wire processing machines and general high-precision positioning applications. It delivers 10A continuous output current (15A peak) with sinusoidal commutation for smooth torque, supporting position/speed/torque control modes with 23-bit encoder feedback (131,072 pulses/rev) for sub-micron accuracy. The drive integrates robust protection (overcurrent/overvoltage/overtemperature/short-circuit/phase loss), modular I/O (8 digital inputs, 4 digital outputs, 2 analog inputs), and multiple communication ports (RS-232, RS-485, optional CANopen) for seamless integration with PLCs/HMIs. It operates on 200-240V AC single-phase input (50/60Hz), with a -10°C~+60°C temperature range and IP20 protection for industrial cabinet installation.

• Core Role: 3-phase sinusoidal servo amplifier; Komax Alpha 411 motion control; precision positioning/speed/torque regulation; industrial automation integration • Model Info: ST110-310 (ST1 series, 10A continuous); Socasin ST1 platform; 3-phase sinusoidal commutation; 23-bit encoder feedback • Key Specs: 200-240V AC single-phase input; 10A continuous /15A peak output; 23-bit encoder feedback; position/speed/torque control modes • Reliability: Overcurrent/overvoltage/overtemperature/short-circuit/phase loss protection; IP20; -10°C~+60°C operation; 5-95% non-condensing humidity

Socapel ST110-310 (5).jpg

2. Technical Specifications

Parameter	Value
Input Voltage	200-240V AC Single-Phase (50/60Hz)
Output Current	10A Continuous, 15A Peak (3-Phase)
Control Modes	Position, Speed, Torque (Configurable via DIP Switches/Software)
Feedback	23-Bit Absolute Encoder (131,072 Pulses/Rev); Resolver Optional
Communication	RS-232, RS-485 (Modbus RTU); Optional CANopen Expansion
I/O Interface	8 Digital Inputs (24V DC), 4 Digital Outputs (Relay/Transistor), 2 Analog Inputs (0-10V/4-20mA)
Protection	Overcurrent, Overvoltage, Overtemperature, Short-Circuit, Phase Loss, Undervoltage, ESD
Dimensions (W×H×D)	120×290×340mm; Weight: 6kg

2. Komax Alpha 411 Integration & Key Features

The ST110-310 is factory-tuned for Komax Alpha 411 wire processing machines, supporting direct integration with Komax motion controllers via RS-485 Modbus RTU for real-time position/speed synchronization. Key features include:

• Komax Optimization: Pre-configured motion profiles for wire cutting/stripping/crimping; 23-bit encoder feedback for sub-micron positioning accuracy • Sinusoidal Commutation: Smooth torque delivery with minimal ripple; ideal for high-speed, low-noise wire processing operations • Dynamic Response:<5ms settling time; 1kHz current loop bandwidth; 100Hz speed loop bandwidth for rapid motion changes • Modular I/O: 8 isolated digital inputs (start/stop/home limits); 4 outputs (status/fault alarms); 2 analog inputs (speed/torque setpoints) • Communication: RS-485 Modbus RTU (9.6-115.2kbps); DIP switch address/baud rate setting; optional CANopen for multi-axis coordination

Socapel ST110-310 (6).jpg

3. Installation, Configuration & Maintenance

Installation follows standard industrial servo drive protocols: mount on a DIN rail in a ventilated cabinet (IP20), connect 200-240V AC input (earth ground required), wire encoder feedback (23-bit absolute), and connect I/O/communication ports. Configuration is via DIP switches (address/baud rate/control mode) or Socapel’s Windows-based ST1 Config Tool (motion profile tuning, parameter backup, fault diagnostics). Maintenance includes 6-month visual inspections (cooling fan, terminal connections), 12-month electrical testing (output voltage, encoder signal integrity), and fault code checking via front-panel LEDs (power: green; run: amber; fault: red).

• Mounting: DIN rail; IP20; -10°C~+60°C; 5-95% non-condensing humidity; industrial cabinet installation • Configuration: DIP switches for basic settings; ST1 Config Tool for advanced motion tuning; parameter backup/restore • Maintenance: 6-month fan/connection check; 12-month electrical testing; LED fault code diagnosis (7-segment display optional) • Hot-Swap: Not supported; power down before replacement to avoid damage to drive/controller

Socapel ST110-310 (4).jpg

4. Safety, Compliance & Target Applications

The ST110-310 complies with IEC 61800-5-1 (safety), IEC 61000-4 (EMC), and CE/UL standards, with built-in STO (Safe Torque Off) for functional safety. It is ideal for Komax Alpha 411 wire processing, electronics manufacturing (PCB assembly), packaging machinery, and robotic automation—where precision motion, reliability, and Komax compatibility are critical.

• Safety: STO (Safe Torque Off); overcurrent/overvoltage/overtemperature protection; ESD protection (±8kV contact, ±15kV air) • Compliance: CE, UL, IEC 61800-5-1, IEC 61000-4 EMC • Applications: Komax Alpha 411 wire processing; electronics manufacturing; packaging machinery; robotic automation; general precision positioning • Warranty: 12-month Socapel factory warranty; 24-month warranty for refurbished units from authorized distributors
