EATON XV-440-10TVB-1-13-1 10.4" Industrial HMI Touch Panel--KIMI

Part number：EATON XV-440-10TVB-1-13-1
Product Origin：America
HS CODE：8443919090
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

EATON XV-440-10TVB-1-13-1 10.4" Industrial HMI Touch Panel (XV400 Series)

Intuitive HMI-PLC Integration for Seamless Industrial Control & Monitoring

1. Product Overview

The EATON XV-440-10TVB-1-13-1 is a 10.4-inch industrial HMI touch panel from the XV400 series, designed for intuitive operator control and real-time process monitoring in manufacturing, packaging, material handling, and energy management systems. It features a VGA (640×480) color TFT LCD with infrared touch technology (anti-glare laminated safety glass) for reliable operation in harsh industrial environments, even with gloves. The panel supports HMI-PLC functionality (retrofittable via license) with Windows CE OS, enabling custom logic development and seamless integration with Eaton PLCs and third-party controllers via Ethernet (10/100Base-TX), RS232, CAN/easyNet, and USB (Host/Device) interfaces. Its compact form factor (345×260×88mm, ~2.8kg) and IP65 front/IP20 rear protection allow embedded mounting in control cabinets, while a wide operating temperature range (0°C to +50°C) and 32W power consumption ensure reliable 24/7 operation. With UL 60950-01 and CSA-C22.2 No. 60950-01 certifications, it meets global industrial safety standards for mission-critical applications.

EATON XV-440-10TVB-1-13-1 (1).png

Key Specifications

• Manufacturer: Eaton (formerly Klockner Moeller)

• Model: XV-440-10TVB-1-13-1 (XV400 Series 10.4" HMI-PLC Panel)

• Display: 10.4" Color TFT LCD, VGA (640×480) Resolution, 65,536 Colors

• Touch Technology: Infrared (IR), Laminated Safety Glass, Anti-Reflective

• Power Supply: 24 V DC (-15% to +20%), 32W Max Power Consumption

• Communication Interfaces: 1×Ethernet (10/100Base-TX), 1×RS232, 1×CAN/easyNet, 2×USB Host, 1×USB Device

• Expansion Slots: 2×CompactFlash (CF) Card Slots, 2×Communication Module Slots

• Protection Rating: IP65 Front, IP20 Rear (IEC 60529)

• Operating Temperature: 0°C to +50°C, Storage: -20°C to +60°C

• Dimensions (W×H×D): 345mm × 260mm × 88mm, Weight: ~2.8kg (6.17lb)

• Certifications: UL 60950-01, CSA-C22.2 No. 60950-01, CE

• Operating System: Windows CE (License Required), PLC Function Retrofit via LIC-PLC-MXP-MEDIUM (140390)

EATON XV-440-10TVB-1-13-1 (5).png

2. Core Features

• HMI-PLC Integration: Retrofittable PLC functionality via license for standalone control logic execution.

• Multi-Protocol Communication: Ethernet, RS232, CAN/easyNet, and USB for seamless connectivity to PLCs, drives, and sensors.

• Rugged Design: IP65 front protection resists dust, water, and chemical exposure; anti-glare glass for outdoor/bright environments.

• Flexible Expansion: 2 CF card slots for data logging/OS storage; 2 communication slots for optional fieldbus modules.

• Intuitive Operation: Infrared touch works with gloves; 65k-color display for clear process visualization and alarm indication.

• Global Compliance: UL/CSA/CE certifications for use in North American and European industrial networks.

• Low Power Consumption: 32W max power draw for energy-efficient 24/7 operation.

EATON XV-440-10TVB-1-13-1 (4).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original.
Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if
you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Manufacturing Automation: Machine control, process parameter adjustment, and production line monitoring.

• Packaging Machinery: Recipe management, filling line speed control, and fault diagnosis.

• Material Handling: Conveyor system supervision, palletizing robot control, and warehouse inventory tracking.

• Energy Management: HVAC control, power distribution monitoring, and renewable energy system visualization.

• Water & Wastewater: Pump station control, chemical dosing monitoring, and treatment process visualization.

• Food & Beverage: Batch processing control, temperature/humidity monitoring, and compliance logging.

EATON XV-440-10TVB-1-13-1 (2).png

4. Installation & Maintenance

Installation: Embedded mounting in control cabinet (4-hole front plate). Connect 24 V DC power to terminal block; wire Ethernet/RS232/CAN for communication. Insert CF card for OS/license; install optional communication modules in expansion slots. Verify PWR/COM LEDs are active.

Configuration: Use Eaton XV Developer software to design HMI screens, configure PLC logic (if licensed), and set up communication protocols. Load project files via USB or CF card for offline deployment.

Maintenance: Monthly checks: Clean front panel with a soft cloth; inspect power/communication connections. Annual: Test touch accuracy via built-in calibration tool; verify CF card integrity and backup project data. Ensure ventilation for heat dissipation (32W).

Fault Diagnosis: Red PWR LED = Power supply fault (check 24 V DC voltage). Flashing COM LED = Communication error (verify network settings/cable). Touch unresponsiveness = Recalibrate via Windows CE control panel.

Technical Document | EATON XV-440-10TVB-1-13-1 | 10.4" HMI-PLC Touch Panel for Industrial Automation
