Baumüller BUM60-12/24-54-B-001 BUM60 Series Servo Power Unit

Product Description

The BUM60-12/24-54-B-001 is a Mono Power Unit from Baumüller BUM60 series, a compact servo power module for multi-axis drive systems. It accepts 3-phase 400–480V AC input, delivers 12A continuous output current for servo motor control. It works together with control cassette boards to realize high-performance vector control, suitable for dynamic motion control of printing, textile, plastic and metalworking machinery. It supports DC bus sharing among multiple axes and is widely used as spare part for retrofitting old Baumüller drive cabinets.

Features

• 3-phase 400–480V AC input, 12A continuous output, 0–300Hz output frequency
• Modular design: power base + pluggable control cassette for flexible configuration
• Supports DC bus coupling, common DC bus for multi-axis synchronization
• High dynamic vector control, compatible with Baumüller synchronous / asynchronous motors
• Built-in comprehensive protection: overcurrent, overvoltage, overheat, earth fault, phase loss
• Status LED indicators for power, fault and ready signals
• CE and UL certified, cabinet-mounted, robust for continuous industrial operation
• Diagnostic data and parameter setup via Baumüller ProDrive commissioning software

Application Scenarios

• Printing press, paper processing and packaging machine multi-axis motion control
• Plastic extruder, injection molding and blow molding equipment drive systems
• Textile machinery, metal cutting and forming machine servo axes
• Automation production line synchronous positioning and tension control
• Baumüller BUM60 rack maintenance, spare parts replacement and machine retrofit

FAQ

Q: What does BUM60 stand for?
A: BUM60 is Baumüller Mono Power Unit series, a standalone servo power module without built-in control logic.

Q: Does it need a control cassette?
A: Yes, it must be fitted with a matching control cassette to run, the power unit alone cannot work.

Q: What software is used for commissioning?
A: Baumüller ProDrive software for parameter configuration, monitoring and fault trace analysis.

Q: Is this series still in production?
A: BUM60 series is legacy, mainly supplied as surplus, refurbished and replacement spare parts.
