151X1233DB02SA02 General Electric 10kW Wind Turbine DC Pitch Converter, Rev A

Product Description

151X1233DB02SA02 Rev A is a heavy-duty DC pitch converter from GE 151X series for wind turbine pitch control systems. This integrated power conversion assembly consists of BAA control board, CAA power board and converter/diode assembly, with 10kW continuous output and peak power up to 25kW, nominal 100A current rating. It converts DC power and drives pitch servo motors to adjust wind turbine blade angles, maintaining stable wind capture and overspeed protection. It is certified with UL 508C and CSA standards and designed to withstand harsh vibration and temperature conditions inside wind nacelles.

Product Features & Functions

• 10kW continuous power, peak 25kW, 100A nominal current for pitch motor drive
• Integrated control (BAA) and power (CAA) boards with WP2Z/WP5p firmware
• Precise DC motor speed and position control for wind turbine blade pitch adjustment
• Built-in diode rectifier assembly DB+/DB-, S1/S2 bus terminals for power connection
• Real-time closed-loop pitch angle regulation to optimize power generation
• Overspeed protection by feathering blades during wind speed surges
• Comprehensive fault monitoring: overcurrent, overvoltage, overtemperature and short circuit protection
• Rugged mechanical design for nacelle high vibration, wide temperature range operation
• UL 508C and CSA certified for wind energy safety compliance

Application Scenarios

• GE wind turbine nacelle pitch control system
• Onshore and offshore wind farm pitch drive spare replacement
• Wind turbine overhaul, maintenance and retrofit projects
• Wind power safety protection system for blade angle control
• Legacy GE 151X series pitch converter replacement

FAQ

Q: What is 151X1233DB02SA02 used for?
A: It is GE Rev A pitch converter, used to drive pitch motors and control wind turbine blade pitch angle inside the nacelle.

Q: What is the power rating of this pitch converter?
A: Continuous rated power 10kW, peak power 25kW, nominal current 100A.

Q: Is this GE pitch converter still in original production?
A: GE has phased out this legacy 151X pitch converter. Only new old stock, used and refurbished units are available in spare parts market.
