Elau VIA0703D01A0000 ISH070/60022/0/0/00/0/00/00/00 Servo Motor Origina New In Stock
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: Elau VIA0703D01A0000 ISH070/60022/0/0/00/0/00/00/00 – Schneider PacDrive Integrated Servo Motor
Schneider Elau VIA0703D01A0000 (ISH070/60022) | All-in-One Decentralized Servo Motor with Integrated Drive Unit
VIA0703D01A0000 ISH070/60022/0/0/00/0/00/00/00 is an integrated intelligent servo motor manufactured by Elau (Schneider Electric), belonging to the PacDrive iSH decentralized motion series. This model integrates servo drive power stage, high-resolution absolute encoder and SERCOS III bus communication interface into one compact motor housing, eliminating separate cabinet servo drives and drastically cutting cabinet wiring and installation space. ISH070/60022 stands for 70mm flange size, 6000rpm rated speed and 2.2Nm standstill torque; VIA0703D01A0000 is the complete assembly part number. Adopting fiber SERCOS real-time bus, it supports microsecond multi-axis electronic line shaft synchronization, widely used in high-speed packaging, printing and food automation production equipment.
Core Technical Specifications
- Full Part Number: VIA0703D01A0000 | Motor Code: ISH070/60022/0/0/00/0/00/00/00 | Brand: Schneider Elau
- Product Type: Integrated motor + servo drive decentralized servo unit
- Rated Speed: 6000 rpm continuous operating speed
- Standstill Torque M0: 2.2 Nm | Peak Torque Mmax: 8.7 Nm, 3.5x overload capacity
- Main DC Bus Power: 680 VDC; Auxiliary Control Power: 24 VDC
- Continuous Rated Current: 2.70 A, fast dynamic current response for high-speed motion
- Communication: Built-in SERCOS III fiber optic real-time motion bus
- Encoder: Multi-turn high-resolution absolute encoder, position retention after power loss
- Protection Rating: IP65 motor housing for machine frame direct mounting
- Mounting Flange: Standard 70mm square flange
- Operating Temperature: 0°C ~ +55°C | Storage Temperature: -40°C ~ +85°C
- Net Weight: Approximately 4.5kg, lightweight aluminum alloy integrated housing
- Certifications: CE, UL, industrial EMC anti-interference compliance
Main Functional Features
- All-in-one integrated drive-motor design, removes independent cabinet servo drives, greatly reduces cabinet space and wiring workload
- Fiber SERCOS III bus communication, strong anti-electromagnetic interference, supports ultra-fast multi-axis synchronous electronic line shaft control
- 3.5 times peak torque overload performance, fast dynamic response, suitable for frequent high-speed start-stop and precise positioning of packaging equipment
- Multi-turn absolute encoder built-in, no homing required after power cycle, permanent accurate position storage
- Onboard local I/O terminals, directly connect proximity sensors and solenoid valves without extra terminal modules
- Complete hardware self-diagnosis system, front panel LED indicators display power, communication, overload, overheat and encoder faults
- Electronic nameplate auto-recognition, PacDrive controller automatically loads motor parameters without manual configuration
- IP65 dustproof and splash-proof housing, can be mounted directly on equipment frames, adapts to dusty and wet workshop environments
- Fully compatible with PacDrive C200/C400 series motion controllers, supports Elau ShopTalk software for motion programming and fault waveform analysis
Application Industries
- Packaging Machinery: High-speed cartoners, vertical filling sealing machines, labeling and slitting multi-axis synchronous control
- Printing Industry: Gravure and flexo printing machine electronic line shaft high-speed linkage drive system
- Food & Beverage Equipment: Filling machines, wrapping machines, bottle sorting high-precision positioning servo drives
- Pharmaceutical Automation: Blister packaging, tablet filling clean-grade decentralized motion control units
- Equipment Retrofit & Maintenance: Replacement of aging Elau PacDrive packaging production line servo components
Product Picture
