Schneider Electric 140CPU31110 Unity Processor--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

Schneider Electric 140CPU31110 Unity Processor (Modicon Quantum Series)

High-Performance CPU for Large-Scale Industrial Control & Distributed Automation Architectures

1. Product Overview

The Schneider Electric 140CPU31110 is a high-performance Unity processor module from the Modicon Quantum automation platform, serving as the core of large-scale industrial control systems. It integrates a 66 MHz 32-bit RISC processor and 548 kB internal RAM to execute complex logic control, sequence control, and process monitoring tasks with exceptional efficiency and reliability. Featuring versatile communication interfaces and extensive I/O expansion capabilities, it supports seamless integration with local I/O modules, remote I/O stations, distributed I/O networks, HMI devices, and upper-level DCS/SCADA systems, ensuring flexible data exchange in industrial environments. With built-in fault detection, self-diagnostic functions, and compliance with international safety and quality standards (CE, UL, HazLoc), it operates stably in harsh industrial conditions with strong electromagnetic interference (EMI), wide temperature fluctuations (0°C to +60°C), and high vibration levels. It is ideal for manufacturing, oil & gas, power generation, water & wastewater treatment, and infrastructure automation applications where reliable and scalable control is essential for operational efficiency and safety.

140CPU31110 -1.jpg

2. Key Technical Specifications

• Brand & Model: Schneider Electric 140CPU31110

• Product Type: Unity Processor (Modicon Quantum Series)

• Core Function: Logic Control Execution, Sequence Control, Process Monitoring, Data Communication, System Coordination

• Processor: 32-bit RISC; Clock Frequency: 66 MHz

• Internal Memory: 548 kB RAM; Supports PCMCIA Card for Memory Expansion

• I/O Capacity: Local - Up to 27 Slots; Remote - Up to 31,744 Inputs/Outputs; Distributed - Up to 8,000 Inputs/Outputs

• Supported Racks: Up to 2 Local Racks

• Remote I/O Stations: Up to 31 (via S908 Protocol)

• Distributed I/O Stations: Up to 63

• Communication Protocols: Modbus Plus, Modbus RS232/485, Ethernet TCP/IP, Profibus DP, AS-Interface

• Instruction Execution Time: Boolean - 0.12-0.585 µs; Floating-Point - 0.1-0.27 µs

• Power Supply: 5 V DC (Bus Current Requirement: 1.8 A)

• Operating Temperature: 0°C to +60°C; Storage Temperature: -40°C to +85°C

• Protection Features: Overvoltage, Short-Circuit Protection; EMC Compliant with IEC 61000-6-2/4

• Mounting: Modicon Quantum Standard Rack

• Physical Dimensions: 170 mm × 100 mm × 20 mm; Weight: 0.91 kg

• Certifications: CE, UL 508, HazLoc Compliant

140CPU31110 -2.jpg

3. Core Features

• High Processing Power: 66 MHz 32-bit RISC processor ensures fast execution of complex control tasks and quick response to field signals.

• Extensive I/O Expansion: Supports large-scale I/O configurations for local, remote, and distributed automation architectures.

• Versatile Communication Options: Compatible with multiple industrial protocols for seamless integration with various devices and systems.

• Modular Design: Facilitates flexible system configuration and expansion to meet evolving application requirements.

• Advanced Diagnostics: Built-in fault detection and self-diagnostic functions for proactive maintenance and troubleshooting.

• Unity Pro Software Compatibility: Enables intuitive programming, configuration, and system monitoring.

• Robust Industrial Design: Operates reliably in harsh industrial environments with wide temperature range and strong EMI.

140CPU31110 -3.jpg

4. Typical Applications

• Manufacturing: Controls production lines, robotic systems, and quality inspection processes in automotive, electronics, and consumer goods industries.

• Oil & Gas: Manages upstream, midstream, and downstream operations including drilling, refining, and pipeline monitoring.

• Power Generation: Controls thermal, hydro, and nuclear power plants; manages grid connection and energy distribution.

• Water & Wastewater Treatment: Automates pump stations, filtration systems, chemical dosing, and sludge treatment processes.

• Infrastructure Automation: Controls transportation systems, building management, and industrial utilities.

5. Installation & Maintenance

Installation Steps

• Mounting: Install into Modicon Quantum standard rack; secure with locking clips for stable backplane connection.

• Communication Wiring: Connect Modbus Plus, Ethernet, and other communication cables to corresponding ports; use shielded cables for EMI protection.

• Power Connection: Wire 5 V DC power supply to terminal blocks; verify correct voltage and current rating.

• I/O Expansion: Connect I/O modules to the backplane; ensure proper alignment and locking.

• Configuration: Program control logic and set parameters via Schneider Unity Pro software.

• Testing: Power on the processor; check LED indicators (Power, Communication, Fault Status); verify control function execution and data communication.

Maintenance Tips

• Daily: Inspect LED indicators; monitor system logs for processor errors, communication anomalies, or memory issues.

• Weekly: Clean module surface and ventilation slots to prevent dust accumulation.

• Monthly: Verify communication link integrity with diagnostic tools; check memory usage and PCMCIA card health.

• Quarterly: Test power supply stability; inspect isolation resistance.

• Annual: Update processor firmware; replace aging components if necessary.

Technical Document | Schneider Electric 140CPU31110 | Unity Processor | Modicon Quantum Series
