Schneider Electric 416NHM30032A 2-Port MB+ PCI Communication Board--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Schneider Electric 416NHM30032A 2-Port MB+ PCI Communication Board
High - Speed MB+ Network Expansion for Modicon 416 PLC Series
1. Product Overview
The Schneider Electric 416NHM30032A is a 2 - port MB+ (Modbus Plus) PCI communication board specifically designed for the Modicon 416 series PLC systems. It provides a reliable and high - speed communication interface for integrating Modicon 416 PLCs into Modbus Plus networks, enabling data exchange with other PLCs, HMIs, and field devices. The board features dual MB+ ports for network redundancy or expanding connection capacity, supporting a communication rate of 1 Mbps, which ensures efficient data transmission in industrial automation environments. It is widely used in manufacturing, power generation, petrochemical, and other industries, ensuring the stable operation of industrial control systems and the efficient interaction of data.
2. Key Technical Specifications
• Brand & Model: Schneider Electric 416NHM30032A
• Product Type: 2 - Port MB+ (Modbus Plus) PCI Communication Board
• Compatible System: Modicon 416 Series PLC
• Communication Port: 2 Independent MB+ Ports (Redundant or Expansion Application)
• Communication Rate: 1 Mbps (MB+ Network Standard Rate)
• Interface Type: PCI (Peripheral Component Interconnect) Bus
• Network Topology: Bus, Star (With Appropriate Hubs)
• Transmission Medium: Shielded Twisted - Pair Cable (STP) for MB+ Network
• Node Address Range: 0-63 (MB+ Network Node Address Setting)
• Operating Temperature: 0°C to +55°C (32°F to +131°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Relative Humidity: 5% - 95% (Non - Condensing)
• Isolation: Galvanic Isolation Between Ports and System for Anti - Interference
• Dimensions (W×H×D): Standard PCI Card Size (106mm × 175mm × 20mm)
• Weight: Approx. 120g
• Certification: CE, UL, CUL
3. Core Features
• Dual MB+ Ports: Support Network Redundancy to Improve System Reliability, or Expand Connection Capacity for More Devices.
• High - Speed Communication: 1 Mbps Transmission Rate Ensures Real - Time Data Exchange in Industrial Control.
• PCI Bus Interface: Seamless Integration with Modicon 416 Series PLC, Easy Installation and Configuration.
• Galvanic Isolation: Prevents Signal Interference and Protects the System from Voltage Spikes or Transients.
• Flexible Topology: Adapt to Bus or Star Network Topology to Meet Different Site Layout Requirements.
• Wide Temperature Range: Suitable for Most Industrial Working Environments.
• Stable Performance: High - Quality Components and Rigorous Testing Ensure Long - Term Stable Operation.
4. Typical Applications
• Manufacturing: Production Line Control, Robot Control, Material Handling Systems.
• Power Generation: Generator Control, Boiler Control, Auxiliary Equipment Monitoring.
• Petrochemical: Refinery Process Control, Pipeline Monitoring, Storage Tank Management.
• Water & Wastewater: Pump Station Control, Treatment Process Automation, Flow Monitoring.
• Building Automation: HVAC Control, Lighting Control, Security System Integration.
5. Installation & Maintenance
• Installation: Insert into the PCI Slot of Modicon 416 PLC Chassis; Fix with Screws to Ensure Stable Connection.
• Wiring: Connect MB+ Ports to STP Cable; Ensure Proper Shielding and Grounding for Anti - Interference.
• Configuration: Set Node Address via DIP Switches on the Board; Configure Network Parameters with Modicon Programming Software.
• Testing: Check Port Communication Status with Diagnostic Tools; Verify Data Transmission Between PLC and Network Nodes.
• Maintenance: Regularly Inspect Cable Connections and Port Status; Update Firmware If Needed for Optimal Performance.
• Troubleshooting: Use LED Indicators on the Board to Identify Port Activity and Faults for Quick Problem - Solving.
