Schneider Electric ABL4RSM24100 Phaseo Regulated Switching Power Supply

Product Description

The Schneider ABL4RSM24100 is a 240W DIN-rail regulated switch mode power supply from the Phaseo ABL4 series. It supports single-phase or two-phase 120–230V AC input, and provides 24VDC, 10A stable DC output for industrial automation equipment. It is widely used to supply PLC, remote I/O, sensors and relays in control cabinets, equipped with diagnostic relay contact and status LED indicators for power monitoring.

Features

• Rated output: 24VDC, 10A, 240W; 150% temporary overload current for 30 seconds
• Input: 120–230V AC single/2-phase, also accepts 300–350V DC input, 47–63Hz
• Output voltage adjustable, built-in overvoltage, overload, short-circuit and thermal protection, automatic reset
• Green power OK LED and red overcurrent fault LED, plus diagnostic alarm relay contact
• 35mm Omega DIN rail mounting, removable screw terminal blocks for easy wiring
• Operating temperature: -20 ~ +45℃ full load; derating required from 45℃ to 60℃
• Integrated non-replaceable input fuse, efficiency up to 90% at 230V AC
• Compact cabinet design, suitable for continuous 24-hour industrial operation

Application Scenarios

• PLC, DCS and remote I/O station power supply for factory automation
• Packaging machinery, conveyor systems, textile and metal processing equipment
• Water treatment, chemical plant and power plant auxiliary control cabinets
• Sensor, solenoid valve, relay and HMI 24V DC power distribution
• Automation cabinet retrofit, spare parts replacement and maintenance

FAQ

Q: What series is ABL4RSM24100?
A: It belongs to Schneider Phaseo ABL4 power supply family, Modicon automation power supply.

Q: Is this model obsolete?
A: Yes, officially discontinued in 2010, end of service in 2013; available as surplus and refurbished spare parts.

Q: What is the common replacement model?
A: ABL8RPS24100 is the mainstream upgraded 24V 10A replacement option.

Q: What is the diagnostic contact used for?
A: It sends alarm signal to upper control system when output voltage drops or fault occurs.
