ISH100/30058/0/1/00/0/00/00/00 Product Description
The ISH100/30058/0/1/00/0/00/00/00 is an ABB ISH series current transducer designed for high-precision AC and DC current measurement in industrial and power electronic systems. This closed-loop Hall effect current sensor converts primary high current into standardized low-level secondary output signal, providing galvanic isolation between primary power circuit and control side. It adopts compact modular housing, high bandwidth and low temperature drift design, delivering stable and accurate current feedback for closed-loop control. The model coding defines measuring range, output type, mounting form and optional features, suitable for continuous operation under high electrical noise environments.
Product Features
- Closed-loop Hall principle, high accuracy for measuring AC, DC and pulsed current
- High galvanic isolation between primary high-current circuit and secondary measurement circuit
- Wide frequency bandwidth, fast response for dynamic current waveform capture
- Low temperature drift and excellent linearity, maintains consistent measurement performance across operating temperature range
- Compact mechanical structure, easy panel or busbar mounting for cabinet integration
- Built-in overrange and over-temperature protection to prevent sensor damage from abnormal operating conditions
- Low power consumption secondary circuit, compatible with PLC, servo controller and data acquisition systems
- Robust housing with good immunity against electromagnetic interference in power conversion cabinets
Application Scenarios
- Medium and low voltage frequency converter and inverter current monitoring
- Uninterruptible power supply (UPS) and energy storage converter control systems
- DC charging piles and power conversion equipment closed-loop current feedback
- Industrial welding power supply and high-power rectifier measurement
- Wind turbine and photovoltaic power generation converter current detection
- Test benches for power electronics and motor drive laboratory measurement
- Railway auxiliary power unit and industrial power quality monitoring systems
Frequently Asked Questions
A1: It uses closed-loop Hall effect principle, which offers high precision, fast response and galvanic isolation for AC, DC and impulse current measurement.
A2: Closed-loop design has better linearity, lower temperature drift and higher bandwidth, suitable for high-precision dynamic current control applications.
A3: Primary busbar eccentricity, strong external magnetic field interference, unstable secondary supply voltage and excessive operating temperature will lead to reading offset.
A4: It depends on output signal type. If it is current output, an external precision burden resistor is usually required to convert to voltage signal for acquisition.
A5: Keep primary conductor centered inside the sensor aperture; avoid placing magnetic materials nearby; ensure adequate ventilation to prevent overheating during long-time high-load operation.
