ELAU / Schneider MC‑4/11/22/400 Product Description
The MC‑4/11/22/400 (alternate part number VDM01D22AA00 / 13130254) is a 4th‑generation single‑axis integrated servo drive for Schneider ELAU PacDrive M motion‑control platform. It integrates mains rectifier, power inverter and full digital triple‑loop controller inside one unit. Rated 22 A continuous output current for 3‑phase 380‑480 VAC supply, it adopts forced‑air cooling and SERCOS‑III fiber‑optic real‑time bus interface, dedicated for high‑dynamic multi‑axis automation machines. Original production is discontinued, widely used as critical spare‑part for legacy packaging‑industry production lines.
Product Features
- All‑in‑one single‑axis servo amplifier, integrated rectifier, power stage and position‑speed‑torque triple‑loop control
- 3‑phase 380‑480 VAC main power input, 24 VDC auxiliary control supply; 22 A RMS continuous output current, max output frequency up to 600 Hz
- SERCOS‑III optical fiber real‑time fieldbus for high‑speed multi‑axis synchronization with PacDrive master controller
- Supports EnDat, Hiperface and resolver feedback signals for synchronous servo motors (SM105 / SM140 series)
- Built‑in STO Safe‑Torque‑Off safety function for machine‑safety compliance
- Forced fan cooling design for heavy‑duty cyclic‑load operation; IP20 protection for cabinet panel‑mount installation
- Supports position‑loop, speed‑loop and torque‑loop control modes for complex motion‑profile execution
- Parameter configuration via ELAU PacDrive engineering software; supports fault waveform capture and comprehensive drive diagnostics
Application Scenarios
- High‑speed packaging machinery, cartoners, form‑fill‑seal and case‑packing production lines
- Printing, converting and label‑processing equipment multi‑axis motion‑control systems
- Material‑handling automation, gantry robots and pick‑and‑place high‑dynamic drive axes
- Food & beverage processing automated machinery and processing‑line retro‑fit projects
- Pharmaceutical packaging equipment requiring precise synchronized multi‑axis movements
- Existing PacDrive‑M platform equipment spare‑part replacement and maintenance projects
- Special‑purpose automation machines with high‑accuracy, high‑speed cyclic‑motion requirements
Frequently Asked Questions
A1: It must pair with PacDrive‑M main controller via SERCOS‑III fiber‑optic bus; it cannot run standalone without master control unit.
A2: Check encoder cable integrity and locking status, motor feedback connector, 24 V encoder power supply, and verify feedback‑type parameter matches actual motor encoder hardware.
A3: Hot‑swap is not allowed. Cut off both main 400 V power and 24 VDC control power, follow official ELAU maintenance procedures before drive replacement.
A4: Inspect cooling‑fan operation status, check cabinet ventilation and ambient temperature, confirm air‑inlet / air‑outlet is not blocked by dust and debris.
A5: Upload full parameter set via PacDrive engineering software; saved project files can be downloaded to replacement drive for fast commissioning during spare‑part swap.
