Bently Nevada ANA-D3510-100-A (A1) 10-inch Industrial LCD Display for 3500/94M--KIMI
- Part number：ANA-D3510-100-A1
- Product Origin：America
- HS CODE：8479909090
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Bently Nevada ANA-D3510-100-A (A1) 10-inch Industrial LCD Display for 3500/94M
Class I, Div 2 Hardened LCD for 3500 System Vibration & Machinery Status Visualization
1. Product Overview
The Bently Nevada ANA-D3510-100-A (A1) is a 10-inch industrial-hardened LCD display designed for the 3500/94M VGA Display Monitor System, providing real-time visualization of machinery vibration, position, and protection status data from 3500 racks. Certified for Class I, Division 2 hazardous locations (ATEX/IECEx Zone 2, cCSAus), it supports VGA video input, multiple mounting styles (19" rack, panel, face, independent), and integrates with 3500/94M I/O modules and display router boxes for multi-rack monitoring. Ideal for power generation, oil & gas, petrochemical, and heavy manufacturing, it enables on-site operators to monitor critical equipment health, configure alarms, and troubleshoot issues without accessing the control room.
2. Key Technical Specifications
• Brand & Model: Bently Nevada ANA-D3510-100-A (A1, 10” Industrial LCD Display)
• Product Type: Industrial Hardened LCD Display for 3500/94M VGA System
• Core Function: Real-time 3500 System Data Visualization, Alarm Monitoring, Status Display
• Display: 10” Diagonal LCD, VGA Resolution (640×480), 250 cd/m² Brightness
• Video Input: VGA (via 3500/94M I/O Module or Display Router Box)
• Power Input: DC 16–62 V / AC 85–260 V (45–65 Hz) / AC 20–55 V (45–65 Hz)
• Hazardous Location Certifications: Class I, Div 2; ATEX/IECEx Zone 2; cCSAus
• Mounting Options: 19" EIA Rack, Panel, Face, Independent Housing
• Operating Temperature: -20°C to +60°C (-4°F to +140°F)
• Storage Temperature: -30°C to +70°C (-22°F to +158°F)
• Dimensions: 254 mm × 203 mm × 51 mm (10.0 in × 8.0 in × 2.0 in)
• Weight: Approx. 2.7 kg (6.0 lbs)
• Accessories: 120M8155-01 (Base PN), 107M3696-01 (3 ft Rack Cable), 149356-01 (Router Box)
3. Core Features
• Industrial Hardened Design: Resists shock, vibration, dust, and temperature extremes.
• Hazardous Location Certified: Safe for Class I, Div 2 / Zone 2 Hazardous Areas.
• Multi-Mount Flexibility: 19" Rack, Panel, Face, or Independent Housing for Any Installation.
• 3500 System Integration: Works with 3500/94M I/O Modules & Router Boxes for Multi-Rack Data.
• VGA Video Support: Displays Real-Time Vibration, Position, and Protection Status.
• Bright, Readable Screen: 250 cd/m² Brightness for Indoor/Outdoor Industrial Environments.
• Wide Power Input Range: DC 16–62 V / AC 85–260 V for Global Industrial Power Systems.
4. Typical Applications
• Power Generation: Turbine/Generator 3500 System Local Monitoring (19" Control Room Rack).
• Oil & Gas: Compressor/Pump 3500 System On-site Status Display (Hazardous Area Panel Mount).
• Petrochemical: Reactor/Heat Exchanger Multi-Rack Data Visualization via Display Router Box.
• Heavy Manufacturing: Motor/Gearbox Alarm Monitoring & Troubleshooting (Independent Mount).
• Marine Propulsion: Main Engine 3500 System Status Display (Shipboard Panel Mount).
• Mining: Crusher/Conveyor 3500 System Real-Time Data Visualization (Rack Mount in Control Hut).
5. Installation & Maintenance
Installation Steps
• Mounting: Choose 19" Rack/Panel/Face/Independent Mount (Use 122M3368-01 Face Mount Kit).
• Wiring: Connect VGA (107M3696-01 Cable for 3 ft Rack Mount) & Power (Match Input Range).
• Integration: Link to 3500/94M I/O Module or 149356-01 Display Router Box (Multi-Rack).
• Configuration: Set Display Resolution (640×480) & Brightness via On-screen Menu.
• Testing: Verify Video Signal, Power Stability, and Hazardous Area Compliance.
Maintenance Tips
• Daily: Check Display Power, Video Signal, and Brightness (Ensure Readable in All Lighting).
• Weekly: Inspect VGA/Power Cables & Connectors for Damage/Loose Connections.
• Monthly: Clean Screen (Use Lint-Free Cloth) & Validate Hazardous Location Sealing.
• Quarterly: Test Power Input Range & VGA Signal Integrity (Replace Cables if Corrupted).
• Annual: Calibrate Brightness/Contrast & Update Display Firmware (Per Vendor Guidelines).
