PFVL141C-50,0 MN  3BSE024994R5000 Millmate load cell

The PFVL141C-50,0 MN (3BSE024994R5000) is a high-precision rolling force load cell in the ABB Millmate series.

Designed based on ABB's unique Pressductor® magnetostrictive effect principle, it is specifically used in the rolling mill systems of the steel industry.

It can measure with extreme precision the huge rolling force of up to 50 meganewtons (MN) between the rolls, that is, the vertical pressure acting on the rolled material.

Its robust industrial-grade design and high output signal characteristics ensure outstanding measurement accuracy,

stability and reliability even in the most demanding industrial environments, and it is extremely insensitive to electrical interference or insulation defects.

In modern rolling mill production, PFVL141C-50,0 MN plays a crucial role. It is not only the key to achieving precise roll clearance setting, thereby ensuring the final dimensional accuracy and high quality of the rolled products,

but also capable of real-time monitoring of the true force distribution from the operating side to the drive side. This is crucial for optimizing the rolling process and avoiding uneven wear. In addition,

this sensor can also be used to monitor the bearing condition of the support rollers and the eccentricity of the rolls, which helps to detect potential equipment failures at an early stage, effectively reduce unplanned downtime,

and significantly improve production efficiency and equipment utilization.

Circular load cells	Measuring range 1.6 - 60 MN
Type	PFVL 141C
Nominal load (MN)	1.6, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 12.5, 14, 16, 18, 20, 22, 25, 28, 31, 35, 40, 45, 50, 51.5, 60

Rectangular load cells	Measuring range 0.63 - 56 MN
Type	PFVL 141V
Nominal load (MN)	0.63, 0.80, 1.0, 1.25, 1.6, 2.0, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 12.5, 14, 16, 18, 20, 22, 25, 28, 31, 35, 40, 45, 50, 56

Annular load cells	Measuring range 2 - 28 MN
Type	PFVL 141R
Nominal load (MN)	2.0, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 11.2, 12.5, 14, 16, 18, 20, 22.4, 25, 28

Annular load cells	Measuring range 0.1 – 2.5 MN
Type	QGPR 104/102
Nominal load (MN)	0.10, 0.16, 0.25, 0.40, 0.63, 1.0, 1.25, 1.6, 2.0, 2.5
