PFVL141C-20,0 MN 3BSE024994R2000 Millmate load cell
  • Brand:ABB
  • Part number:PFVL141C-20,0 MN 3BSE024994R2000
  • Product Origin:Sweden
  • Weight:135kg
  • HS CODE:8443919090
  • RMB Market price:100000-150000
  • Warehouse: Spot
  • Warranty: 365 days
  • Quality: Original module
  • Condition: New
  • Shipping method: Courier delivery

  • Contact person: LI MING
  • Contact number: +86 18059884790
  • WeChat:18059884790
  • E-mail: plc66@qq.com

Product Description

PFVL141C-20,0 MN  3BSE024994R2000 Millmate load cell

Pfvl141c-20,0 MN (3BSE024994R2000) is a high-precision rolling force load cell in the ABB Millmate series.

Designed based on ABB's unique Pressductor® magnetostrictive effect principle, it is mainly used in the rolling mill systems of the steel industry, capable of measuring the rolling force between the rolls with extreme precision,

that is, the vertical pressure acting on the rolled material. Its robust design and high output signal capability enable it to maintain outstanding measurement accuracy and reliability even in harsh industrial environments,

and it is extremely insensitive to insulation defects.





Product Number: 3BSE024994R2000

ABB type name: PFVL141C-20,0 MN

Catalogue Description: PFVL 141C-20,0 MN Millmate load cell

Medium description: Millmate load cell

Minimum order quantity: 1 piece

Order multiple: 1 piece

The gross weight of the first grade package is 135 kilograms

Package level 1 unit: 1 piece

Part type: New

Net weight of the product: 135 kilograms








Technical information

Pfvl141c-20 0 MN Millmate load cell

Cable length (meters) : 3BSE019281R11

Circular installation male contacts, contact length 60-152 millimeters

3BSE024479Rxx

Fixed connection cable with protective hose 3BSE028013R1

Fixed connection cable, with protective hose, kerosene resistant

3BSE028013R2

Fixed connection cable, with hose, kerosene resistant

And acid-resistant steel wire rope 3BSE028013R3


Data

Circular load cells
Measuring range 1.6 - 60 MN
TypePFVL 141C MRF Circular LC resource_small
Nominal load (MN)1.6, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 12.5, 14, 16, 18, 20, 22, 25, 28, 31, 35, 40, 45, 50, 51.5, 60


    Rectangular load cells
    Measuring range 0.63 - 56 MN
    TypePFVL 141VMRF Rectangular LC resource_small
    Nominal load (MN)0.63, 0.80, 1.0, 1.25, 1.6, 2.0, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 12.5, 14, 16, 18, 20, 22, 25, 28, 31, 35, 40, 45, 50, 56


    Annular load cells
    Measuring range 2 - 28 MN
    TypePFVL 141RMRF Annular LC resource_small
    Nominal load (MN)2.0, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 11.2, 12.5, 14, 16, 18, 20, 22.4, 25, 28


    Annular load cells
    Measuring range 0.1 – 2.5 MN
    TypeQGPR 104/102QGPR roll force load cells
    Nominal load (MN)0.10, 0.16, 0.25, 0.40, 0.63, 1.0, 1.25, 1.6, 2.0, 2.5


     PFVL
     QGPR
    Accuracy class (% of Fnom)± 0.5 ± 1.0
    Linearity deviation (% of Fnom)≤± 0.5 ≤± 1.0
    Hysteresis (% of Fnom)≤ 0.2 ≤ 0.2
    Repeatability error (% of Fnom)≤ ± 0.1 ≤ ± 0.05
    Compression (mm at Fnom)0.05 0.05
    Calibration error (% of Fnom)0.1 0.1
    Compensation for min. error+20 - +80°C +20 - +80°C
    Zero point drift≤ ± 0.01%/°C ≤ ± 0.005%/°C
    Sensitivity drift≤ ± 0.01%/°C ≤ ± 0.01%/°C
    Working temperature range-10 - +90°C -10 - +80°C
    Max. permitted short-term temp.+110°C +110°C
    Storage temperature range-40 - +90°C -40 - +90°C


    Load cells play a crucial role in the rolling mill system. Not only does it help achieve the correct setting of roll clearance, ensuring the dimensional and quality accuracy of rolled products,

    but it can also monitor the true force distribution from the operating side to the drive side. In addition, PFVL141C-20, 0MN can also be used to monitor the eccentricity of the support roller bearings and rolls,

    which is helpful for predicting equipment failures and reducing downtime. In addition to steel rolling, it is also applicable to other industrial fields that require high-precision tension or force measurement, such as metal processing, textiles,

    papermaking and plastic processing, etc.
