Schneider Modicon 140ACO13000 Multi-range Analog Output Module

Product Description

The Schneider 140ACO13000 is an 8-channel multi-range analog output module for Modicon Quantum PLC platform. It converts digital control signals from the Quantum CPU into standard analog current signals to drive field actuators, control valves, positioners and variable transmitters. It supports multiple current ranges and open-loop detection, widely deployed in process control industries for continuous regulation loops.

Features

• 8 analog output channels, multi-range: 4-20mA, 0-20mA, 0-25mA
• Accuracy: ±0.2% full scale at 25°C, isolation of 1780V AC between channels and backplane bus
• Loop supply voltage 6–30VDC, supports open circuit detection under 4-20mA mode
• 5ms update time, settling time 3.2ms to ±0.1% final value
• Hot-swappable in Quantum rack, communicates via Quantum backplane bus
• LED indicators for module run status, fault and channel alarm information
• Max power consumption 5W, bus current draw 550mA
• Configured and programmed through Unity Pro software

Application Scenarios

• Chemical, oil & gas and refinery process closed-loop control
• Power plant auxiliary control, water and wastewater treatment automation
• Control valve, electric actuator, frequency converter and positioner driving
• Flow, pressure, temperature and liquid level regulation control loops
• Modicon Quantum rack expansion, spare parts replacement and system retrofit

FAQ

Q: Which PLC series does it belong to?
A: It is an analog output module for Schneider Modicon Quantum PLC.

Q: What signal ranges are supported?
A: 4-20mA, 0-20mA and 0-25mA current output options.

Q: Is this module discontinued?
A: Yes, it is end-of-life; supply is mainly original surplus and fully tested refurbished spare parts.

Q: What software is used for configuration?
A: Unity Pro is the official programming and configuration software for Modicon Quantum hardware.
