• Full Part Number: VIA0703D02F0000 | Motor Code: iSH070/60022/0/0/00/0/00/11/00 | Brand: Schneider Elau
• Structure Type: Integrated motor + servo drive all-in-one intelligent servo unit
• Rated Speed: 6000 rpm continuous operating speed
• Standstill Torque M0: 2.2 Nm | Peak Torque Mmax: 8.7 Nm (3.5x overload capacity)
• Main Power Input: 680 VDC DC bus power supply; Control Auxiliary Power: 24 VDC
• Rated Drive Current: 2.70 A continuous, high dynamic current response
• Communication Interface: Built-in SERCOS III fiber high-speed real-time motion bus
• Encoder: Multi-turn high-resolution absolute encoder, electronic nameplate automatic identification
• Protection Grade: IP65 motor housing, suitable for machine body on-site installation
• Flange Size: 70mm square flange standard mounting size
• Operating Temperature: 0°C ~ +55°C | Storage Temperature: -40°C ~ +85°C
• Net Weight: Approx. 4.5kg, compact integrated aluminum alloy housing
• Certifications: CE, UL, industrial EMC anti-interference compliance

• Integrated drive and motor design, cancel independent cabinet servo drive, save over 90% electrical cabinet space and wiring workload
• SERCOS fiber bus communication, strong anti-electromagnetic interference, realize microsecond-level multi-axis electronic line shaft synchronous control
• 3.5 times peak torque overload capability, high dynamic response, adapt to high-speed start-stop and fast positioning of packaging machinery
• Built-in multi-turn absolute encoder, no zero return after power failure, support accurate position retention for long-term shutdown
• On-board local DI/IO signal terminals, directly connect proximity switches, solenoid valves and other on-site actuators without additional terminal modules
• Complete self-diagnosis system, front panel LED indicators for power, communication, overload, overheat and encoder fault alarm
• Electronic type plate automatic recognition, PacDrive controller automatically read motor parameters without manual parameter configuration
• IP65 dustproof and waterproof housing, can be directly installed on the equipment frame, adapt to dust and splash liquid production workshop environment
• Perfect matching with PacDrive C200/C400 series motion controllers, support ELAU ShopTalk programming software for motion logic editing and fault waveform recording

• Packaging Machinery: High-speed cartoner, vertical form fill seal machine, labeling and slitting multi-axis synchronous control
• Printing Industry: Gravure printing, flexo printing machine electronic line shaft high-speed linkage drive system
• Food & Beverage: Filling machine, wrapping machine, bottle sorting high-precision positioning servo control
• Pharmaceutical Equipment: Blister packaging, tablet filling machine clean-grade decentralized motion control unit
• Industrial Automation Retrofit: Replacement and maintenance of old Elau PacDrive packaging production line servo equipment

Product Picture
