ABB HC800 | High-Performance Controller for Symphony Plus DCS
Redundant Design, Multi-Processor Parallel Computing, PN800 Plant Network Integration for Power Generation, Oil & Gas, Petrochemicals
1. Product Overview
The ABB HC800 is a high-performance redundant controller for the ABB Symphony Plus distributed control system (DCS), engineered to deliver reliable, real-time process control and seamless integration with I/O modules, communication processors (e.g., CP800), and operator stations in mission-critical industrial environments. It features a redundant architecture with dual 32-bit ColdFire processors (256 MHz), 64 MB RAM, and 4 MB ROM, enabling parallel processing of control algorithms, data acquisition, and system diagnostics for fast, deterministic control responses. The HC800 integrates the PN800 Plant Network for high-speed inter-controller, controller-to-I/O, and controller-to-server communication, supporting hot-standby operation for uninterrupted control during component failure. With a 24 VDC system bus power supply, operating temperature range of 0°C to +70°C, and compliance with IEC 61010-1 and UL 508 safety standards, it ensures robust performance in power generation, oil & gas, petrochemical, and pulp & paper applications, serving as the core of scalable, fault-tolerant DCS solutions with minimal downtime and maximum operational efficiency.
Key Specifications
• Model: HC800 (High-Performance Redundant Controller for ABB Symphony Plus DCS)
• Redundant Architecture: Dual redundant design for automatic failover and 24/7 operation
• Processor: Dual 32-bit ColdFire, 256 MHz for parallel control processing and diagnostics
• Memory: 64 MB RAM, 4 MB ROM; Lithium button cell for data backup during power loss
• Communication: PN800 Plant Network (100 Mbps) for real-time data exchange; Compatible with CP800 for multi-protocol integration
• I/O Integration: Supports ABB Symphony Plus I/O modules via system backplane; Max. I/O capacity: 4096 points
• Power Supply: 24 VDC ±10% (from system bus); Typical power consumption: 15 W
• Environmental: Operating Temperature: 0°C to +70°C (+32°F to +158°F); Storage: -20°C to +70°C (-4°F to +158°F); Humidity: 5% to 95% (Non-condensing)
• Dimensions: 170.18mm × 73.66mm × 243.84mm (6.7" × 2.9" × 9.6"); Net Weight: 1.2 kg
• Certifications: CE, UL 508, IEC 61010-1, RoHS (EU Directive 2011/65/EU)
2. Core Features
• Redundant Controller Design: Dual CPU architecture with automatic hot-standby failover for zero-downtime process control.
• PN800 Plant Network: High-speed backbone for real-time inter-controller and controller-to-I/O data transfer (100 Mbps).
• Parallel Processing: Dual ColdFire 256 MHz CPUs enable simultaneous execution of control logic, diagnostics, and data routing.
• Seamless Integration: Works with CP800 communication processor for Modbus TCP, OPC UA, and DNP3 connectivity to SCADA/MES systems.
• Scalable I/O Capacity: Supports up to 4096 I/O points for large-scale process control applications.
• Data Backup: Lithium button cell preserves configuration and real-time data during power loss, ensuring system integrity.
• Fault Diagnostics: Built-in self-diagnostics for proactive maintenance and rapid fault isolation.
• Industrial-grade Reliability: Wide temperature range, vibration/shock resistance, and EMC compliance for harsh industrial sites.
