ABB SYCHROTACT 5 3BHB006716R0277 SYN5302a-Z,V277--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB SYCHROTACT 5 3BHB006716R0277 SYN5302a-Z,V277

Dual-Channel Automatic Synchronizer | Generator-to-Grid Connection | Redundant Protection | IEC 61850/Modbus/Profibus

1. Core Product Overview

The ABB SYCHROTACT 5 3BHB006716R0277 (SYN5302a-Z,V277) is a dual-channel automatic synchronizer for power generation and industrial grid applications, enabling safe, precise synchronization of generators to grids, busbars, or synchronous lines with<1° phase angle accuracy and <0.02Hz frequency matching. As part of ABB’s 5th-gen SYCHROTACT series, it supports single/dual-channel redundant operation (<5ms failover) for fault-tolerant grid connection, handling up to 7 power circuit breakers with independent parameters. The module uses dual 32-bit embedded processors (channel A/B) for redundant measurement, 64MB Flash/128MB SDRAM for data buffering, and dual 24V DC redundant power inputs for 24/7 reliability. Designed for panel/cabinet mounting (IP20), it operates in -25°C~+70°C industrial environments with conformal coating, and integrates with ABB System 800xA/DCS for centralized monitoring/diagnostics.

• Core Role: Generator-grid synchronization; busbar paralleling; dead bus/dead line monitoring; dual-channel redundant control; breaker closing supervision • Model Info: 3BHB006716R0277 (order code); SYN5302a-Z,V277 (module code); SYCHROTACT 5 series; dual-channel V277 version • Key Specs: 24V DC redundant power; dual-channel (A/B);<1° phase accuracy; <0.02Hz frequency matching; 50/60/16.7Hz support • Reliability: Dual CPU/communication/power;<5ms failover; IEC 61850; IP20; conformal coating; IEC 61010-1 compliance

SYCHROTACT 5 3BHB006716R0277

2. Key Technical Specifications

Parameter	Specification
Processor	Dual 32-bit Embedded CPUs (Channel A/B, 200 MHz each)
Power Supply	24V DC Redundant Input (20-30V DC); 15W Max Power Consumption
Synchronization Channels	Dual-Channel (A/B, redundant);<5ms failover; independent parameter sets
Input/Output	3×Voltage Inputs (100-480V AC); 2×Frequency Inputs; 8×Digital Outputs (breaker control, alarms); 4×Digital Inputs (status feedback)
Performance	Phase Accuracy:<1°; Frequency Matching: <0.02Hz; Max Breakers: 7; Sync Time: <2s
Communication	IEC 61850; Modbus RTU/TCP; Profibus DP; LON; 1×Ethernet (RJ45, TCP/IP)
Environment	-25°C~+70°C; 5-95% Non-Condensing Humidity; IEC 60068-2-6 Vibration
Mounting & Protection	IP20; Panel/Cabinet Mount (260×320×125mm); Conformal Coating (Optional)

3. Synchronization Logic & Redundant Architecture

The SYN5302a-Z,V277 uses dual-channel redundant synchronization: Channel A (primary) and Channel B (standby) monitor voltage, frequency, and phase of generator/grid simultaneously, with<5ms failover if a channel fault is detected. It measures 3-phase voltage (100-480V AC), frequency (50/60/16.7Hz), and phase angle, automatically adjusting generator speed/voltage via AVR/governor to meet sync criteria (phase: <1°, frequency: <0.02Hz, voltage: ±5%). It supports up to 7 breakers with independent parameters (sync window, dead band, closing delay) and dead bus/dead line sync for black-start scenarios. Front-panel LEDs (Power: green; Channel A: amber; Channel B: blue; Fault: red) and a fault relay (NO/NC, 2A/24V DC) enable on-site monitoring and remote alarming.

• Sync Logic: Voltage/frequency/phase monitoring; AVR/governor control; breaker closing at optimal phase angle; dead bus/dead line support • Redundancy: Dual-channel (A/B);<5ms failover; independent CPU/communication; cross-channel monitoring • Breaker Control: 7 breakers max; independent parameter sets; closing delay (0-100ms); sync window (0.1-5°) • Monitoring: Front-panel LEDs; fault relay; remote diagnostics via SynView 5; event logging (1000 events)

SYCHROTACT 5 3BHB006716R0277

3. Communication Protocols & Configuration

The SYN5302a-Z,V277 supports IEC 61850 (MMS/GOOSE), Modbus RTU/TCP, Profibus DP, and LON for integration with ABB DCS (System 800xA), SCADA, and third-party control systems. Configuration uses ABB SynView 5 (Windows-based) for advanced setup (channel parameters, breaker config, redundancy, fault logging) and front-panel DIP switches for basic settings (channel priority, baud rate, Profibus address). It features 1×Ethernet (RJ45, TCP/IP) for remote servicing, 1×RS-485 (Modbus RTU/Profibus DP), and 1×RS-232 (service). SynView 5 auto-recommends parameters, stores 1000 events, and enables remote firmware updates via TCP/IP.

• Protocols: IEC 61850 (MMS/GOOSE); Modbus RTU/TCP; Profibus DP; LON; TCP/IP for remote service • Configuration: SynView 5 (advanced); DIP switches (basic); parameter backup/restore; event logging (1000 events) • Integration: ABB System 800xA; SCADA; third-party DCS/HMI; AVR/governor communication • Remote Access: TCP/IP remote service; firmware updates; real-time monitoring/diagnostics via SynView 5

SYCHROTACT 5 3BHB006716R0277

4. System Integration & Industrial Applications

The SYN5302a-Z,V277 integrates with ABB System 800xA, DCS, and third-party SCADA via IEC 61850/Modbus/Profibus, mounting on 35mm DIN rails or panel boards with plug-in terminals for power, voltage/frequency inputs, and breaker control outputs. It is ideal for power generation (thermal/hydro/wind), oil & gas, petrochemical, and industrial cogeneration—where safe, redundant generator-grid synchronization is critical. It complies with IEC 61850, IEC 61010-1, CE, UL, and ATEX Zone 2/Class I, Div 2 (optional conformal coating). It also offers a seamless upgrade path to SYCHROTACT 6 (same size/connections) for future expansion.

• Integration: ABB System 800xA; DCS; SCADA; AVR/governor; breaker control; HMI • Mounting: 35mm DIN rail; panel mount (260×320×125mm); plug-in terminals; IP20 • Certifications: CE, UL, IEC 61850, IEC 61010-1; ATEX Zone 2/Class I, Div 2 (optional); RoHS • Applications: Power generation (thermal/hydro/wind); oil & gas; petrochemical; industrial cogeneration; grid connection

5. Installation, Maintenance & Troubleshooting

Installation: DIN-rail/panel mounting; redundant 24V DC power (polarity check); voltage/frequency input wiring (100-480V AC); breaker control output wiring; DIP switch setup; LED status verification.

Configuration: SynView 5 for channel parameters/breaker settings/redundancy; backup config; integrate with System 800xA for centralized control.

Maintenance: 6-month visual inspection (terminals, LEDs); 12-month input/output testing; fault diagnosis via LEDs/SynView 5; no moving parts (zero mechanical maintenance).

Troubleshooting: Red fault LED = power/channel/overtemperature; check power first; verify voltage/frequency inputs; use SynView 5 for fault codes/event logs.

Replacement: Hot-swap compatible with redundant systems; plug-and-play with pre-saved config for minimal downtime.

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders

Technical Documentation | ABB SYCHROTACT 5 3BHB006716R0277 SYN5302a-Z,V277 | Dual-Channel Automatic Synchronizer
