500CPU03 1HDF700003R5 CPU Module--KIMI

Part number：500CPU03 1HDF700003R5
Product Origin：Sweden
HS CODE：8537109021
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB 500CPU03 (1HDF700003R5) AC500 Series High-Performance CPU Module

Core Controller for Medium & Large-Scale Industrial Automation & Process Control

1. Core Product Overview

The ABB 500CPU03 (order code: 1HDF700003R5) is the flagship core CPU module of the ABB AC500 programmable logic controller series, engineered as the central control unit for medium and large-scale industrial automation systems. It integrates a high-speed 32-bit industrial RISC processor, large-capacity non-volatile memory, multi-protocol industrial communication interfaces, and ABB’s proprietary FBP (Flexible Bus Protocol) for seamless plug-and-play expansion with all AC500 series I/O modules. Built with industrial-grade ruggedness, it supports redundant 24V DC power supply, a wide operating temperature range of -20°C to +70°C, and IP20 front panel protection, ensuring stable and real-time logic operation in harsh industrial environments such as chemical plants, power stations, steel mills, and water/wastewater treatment systems. Fully compliant with IEC 61131-3 programming standards, it supports LD, FBD, ST, IL and SFC programming languages for flexible system configuration and customization.

500CPU03 1HDF700003R5 (3).jpg

• Core Role: AC500 PLC central control; real-time industrial logic calculation; multi-protocol communication management; AC500 I/O module expansion; system fault diagnosis & redundancy control • Model Info: 500CPU03 (base model); 1HDF700003R5 (ABB official order code); AC500 series high-performance CPU • Key Core Specs: 32-bit RISC processor; 200MHz core frequency; 512KB flash program memory; 1MB SRAM data memory; redundant power; -20°C ~ +70°C operating temp • Industrial Reliability: EMC/surge protection; anti-vibration/anti-shock; battery-backed RTC; non-volatile fault logging; hot standby dual CPU support

2. Processing Power & Memory Configuration

The 500CPU03 1HDF700003R5 features a 200MHz 32-bit industrial RISC processor with ultra-fast real-time processing capability, delivering a logic scan speed of<0.1ms per 1k steps—meeting the high-speed control requirements of complex industrial processes and multi-axis automation systems. It is equipped with 512KB of battery-free flash program memory (supports online programming, program backup and firmware upgrade without system shutdown) and 1MB of battery-backed SRAM data memory (ensures critical data retention for over 10 years in power failure). The on-board real-time clock (RTC) with battery backup provides precise time stamping for production data, alarm events and process logs, and the module supports external memory card expansion for large-scale program storage and historical data recording.

500CPU03 1HDF700003R5 (1).jpg

• Processor: 32-bit industrial RISC; 200MHz core frequency;<0.1ms/1k steps scan speed; multi-task real-time scheduling • Memory: 512KB flash (program, battery-free); 1MB SRAM (data, 10+ years battery backup); external memory card expansion • Real-Time Function: Battery-backed RTC; 1μs high-speed timer/counter; interrupt response; precise event time stamping • Programming: IEC 61131-3 compliant; LD/FBD/ST/IL/SFC; online programming/debugging; remote firmware upgrade

3. Communication Interfaces & I/O Expansion

The 500CPU03 integrates a rich set of industrial communication interfaces for seamless connection with upper-level DCS/SCADA systems, lower-level I/O modules and third-party industrial equipment. It features 1×10/100Mbps adaptive Ethernet RJ45 port (supports PROFINET, Modbus TCP, EtherNet/IP and TCP/IP/UDP), 2×RS485 serial ports (supports Modbus RTU, CANopen and custom protocols) and 1×USB 2.0 port (for local programming, data download/upload and program backup). Adopting ABB FBP (Flexible Bus Protocol) for high-speed I/O expansion, it supports up to 256 digital I/O points or 64 analog I/O points, and is fully compatible with all AC500 series I/O modules (500AIM02/500BIM01/500BOM01/500BIO01). The Ethernet port enables remote monitoring, remote programming and system networking, while the RS485 ports support multi-master/slave communication for flexible field bus configuration in distributed automation systems.

• Ethernet: 1×RJ45 (10/100Mbps); PROFINET/Modbus TCP/EtherNet/IP; TCP/IP/UDP; remote monitoring/programming • Serial Ports: 2×RS485; Modbus RTU/CANopen; 9600-115200bps baud rate; multi-master/slave communication • Local Interface: 1×USB 2.0; local programming/debugging; data download/upload; program backup/restore • I/O Expansion: ABB FBP protocol; max 256 DI/DO or 64 AI/AO; compatible with all AC500 I/O modules; hot expansion support

500CPU03 1HDF700003R5 (8).jpg

4. Industrial Reliability & Installation

Designed for harsh industrial environments, the 500CPU03 supports 24V DC redundant power input (18-30V DC) with reverse polarity, overvoltage and short-circuit protection—ensuring uninterrupted system operation in case of single power supply failure, critical for high-availability industrial processes. It complies with IEC 61000-4 for EMC/surge protection and IEC 60068 for anti-vibration (5-50Hz) and anti-shock performance, effectively resisting electromagnetic interference, voltage fluctuations and mechanical shocks in industrial sites. The module features standard 35mm DIN rail mounting with a compact form factor (140×100×65mm), fitting into standard industrial control cabinets, and front-panel LED indicators (Power/Run/Error/Comm/I/O) for real-time visual diagnosis of system status. It also supports dual CPU hot standby configuration, further improving system fault tolerance for critical processes such as power generation and chemical production.

• Power Supply: 24V DC redundant input (18-30V); reverse polarity/overvoltage/short-circuit protection;<10W power consumption • Industrial Protection: IEC 61000-4 EMC/surge; IEC 60068 anti-vibration/anti-shock; IP20 front panel dust protection • Mounting: 35mm standard DIN rail; 140×100×65mm compact dimensions; industrial control cabinet compatible • Diagnostics & Redundancy: Front-panel LED indicators; non-volatile fault logging (1000+ events); dual CPU hot standby; online fault diagnosis

500CPU03 1HDF700003R5 (7).jpg

5. Typical Applications & Industrial Compliance

Key Industrial Sectors: Chemical/petrochemical process control; thermal/hydro/wind/solar power generation; steel/metallurgy automation; water/wastewater treatment; building automation; mining machinery; automotive/packaging manufacturing; cement production.

Core Use Cases: Medium/large-scale PLC system central control; complex industrial process real-time regulation; production line interlock control; distributed automation system management; remote monitoring & control; critical process redundant control; multi-axis motion control.

Certifications & Compliance: IEC 61131-3 (programming); IEC 61010-1 (electrical safety); IEC 61000-4 (EMC); IEC 60068 (environmental testing); CE/UL/RoHS certified; ATEX optional for explosive environments.

Spare Part & Warranty: ABB genuine original module; factory pre-tested for performance/reliability; 18-month standard warranty; lifetime technical support for system configuration/debugging; fully compatible with all AC500 series I/O modules and firmware versions.

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.
