1. Product Overview
The ABB CP800 is a dedicated communication processor module for the HPC800 controller in the ABB Symphony Plus DCS, acting as the core communication hub to enable high-speed PN800 Plant Network communications, ensuring efficient data exchange, real-time process control, and reliable network operation in complex industrial environments. It integrates dual 256 MHz ColdFire 32-bit processors (shared with HPC800), 64 MB RAM, and 4 MB ROM, delivering robust data processing for real-time process data handling, configuration information transfer, alarm/event management, and seamless connectivity with PLCs, sensors, actuators, and third-party systems. With industrial-grade design, 24 VDC power supply via the system bus, an operating temperature range of 0°C to 70°C, and RoHS compliance, it provides stable and secure communication for power generation, oil & gas, petrochemical, and pulp & paper applications, serving as a critical component for building scalable, high-performance distributed control systems with minimal downtime.
Key Specifications
• Model: CP800 (Communication Processor Module for ABB HPC800 Controller)
• System Compatibility: ABB Symphony Plus DCS (HPC800 Controller)
• Processor: Dual ColdFire 32-bit, 256 MHz (Shared with HPC800 Controller)
• Memory: 64 MB RAM, 4 MB ROM; Lithium Button Cell for Data Backup
• Communication: PN800 Plant Network (High-speed System Backbone); Ethernet (10/100Base-T); Serial (RS-232/485); Supports Modbus TCP, OPC UA, DNP3
• Power Supply: 24 VDC ±10% (from System Bus); Typical Power Consumption: 10 W
• Environmental: Operating Temperature: 0°C to +70°C (+32°F to +158°F); Storage: -20°C to +70°C (-4°F to +158°F); Humidity: 5% to 95% (Non-condensing)
• Dimensions: 170.18mm × 73.66mm × 243.84mm (6.7" × 2.9" × 9.6"); Net Weight: 0.99 kg
• Certifications: CE, RoHS (EU Directive 2011/65/EU), IEC 61010-1, UL 508
2. Core Features
• PN800 Plant Network Hub: High-speed backbone for HPC800 controller-to-I/O, controller-to-server, and inter-controller real-time data transfer.
• Multi-protocol Support: Native Modbus TCP, OPC UA, DNP3 for seamless integration with SCADA, MES, and third-party industrial devices.
• Shared Processing Power: Dual ColdFire 256 MHz CPUs enable parallel data processing and communication, ensuring low-latency control responses.
• System Integration: Centralizes alarm/event management, configuration data distribution, and process data routing for Symphony Plus DCS.
• Hot-standby Compatibility: Works with HPC800 redundant configurations for uninterrupted communication during controller failover.
• Data Backup: Lithium button cell preserves configuration and real-time data during power loss, ensuring system integrity.
• Industrial-grade Durability: Wide temperature range, vibration/shock resistance, and EMC compliance for harsh industrial sites.
