1TGE120010R1300 2 - Pole Change - over Contact Low - Voltage Control Relay--KIMI

Part number：ABB 1TGE120010R
Product Origin：America
HS CODE：8537109021
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB 1TGE120010R1300 2 - Pole Change - over Contact Low - Voltage Control Relay

Reliable Switching & Control for Industrial Automation and Power Distribution Systems

1. Product Overview

The ABB 1TGE120010R1300 is a 2 - pole change - over contact low - voltage control relay, which is an important component for industrial automation and power distribution systems, providing reliable switching and control functions for electrical equipment and production processes. It has 2 sets of change - over contacts (1NO + 1NC), and can be expanded to 4 sets if required, supporting flexible circuit switching for motor control, system interlocking, and alarm circuits. The relay is rated for 10A at 250V AC (resistive load) and 5A at 30V DC (inductive load), with a 230V AC coil (50/60Hz universal) and a coil power consumption of ≤5VA, ensuring efficient and energy - saving operation. It features a compact 22.5mm width DIN - rail mounting design, plug - in terminals, and LED indicators for power and contact status, which simplifies installation, wiring, and troubleshooting. With a wide operating temperature range of - 25°C to + 70°C and 5% - 95% RH (non - condensing) humidity resistance, it can operate reliably in harsh industrial environments, making it suitable for motor control, power distribution protection, and process interlocking in power generation, oil & gas, manufacturing, and building automation applications.

ABB 1TGE120010R... Rev.A (1).png

Key Specifications

• Manufacturer: ABB

• Model: 1TGE120010R1300 (2 - Pole Change - over Contact Low - Voltage Control Relay)

• Product Category: Low - Voltage Control Relay (Change - over Contact Type)

• Contact Configuration: 2 sets of change - over contacts (1NO + 1NC), expandable to 4 sets

• Rated Control Capacity: 10A@250V AC (resistive load), 5A@30V DC (inductive load)

• Coil Voltage: 230V AC (50/60Hz universal)

• Coil Power Consumption: ≤5VA

• Response Time: Pull - in time < 15ms, Release time < 10ms

• Indicators: Power LED, Contact Status LED

• Mounting: DIN - Rail (EN 60715 standard), width 22.5mm

• Operating Conditions: Temperature - 25°C to + 70°C, Humidity 5% - 95% (non - condensing)

• Certifications: CE, UL, IEC 61810 - 1 compliant

ABB 1TGE120010R... Rev (5).png

2. Core Features

• 2 - Pole Change - over Contacts: 1NO + 1NC per pole for flexible circuit switching and interlocking.

• High - Current Rating: 10A AC / 5A DC rating supports most low - voltage control applications.

• Universal Coil: 230V AC (50/60Hz) works in global power grids without frequency adjustment.

• Low Power Consumption: ≤5VA coil ensures energy - saving operation and reduces heat generation.

• Compact Design: 22.5mm width saves panel space for dense DIN - rail installations.

• Plug - in Terminals: Tool - free wiring speeds up installation and reduces connection errors.

• LED Status Indicators: Real - time monitoring of power and contact status for quick fault diagnosis.

• Wide Environmental Range: - 25°C to + 70°C operation for harsh industrial sites.

ABB 1TGE120010R... Rev (4).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Motor Control: Star - delta starter interlocking, forward - reverse control, and overload protection circuits.

• Power Distribution: Circuit breaker control, transformer cooling fan switching, and power factor correction.

• Industrial Automation: PLC output interface, process interlocking, and safety circuit switching.

• Building Automation: HVAC system control, lighting switching, and fire alarm interlocking.

• Oil & Gas: Pump control, pipeline valve actuation, and safety shutdown circuit interlocking.

• System Retrofits: Replacement of aging control relays in low - voltage panels to improve reliability.

ABB 1TGE120010R... Rev (3).png

4. Installation & Maintenance

Installation: Mount on EN 60715 standard DIN - rail; connect 230V AC power to the coil terminals. Wire field devices to NO/NC contacts according to the circuit diagram. Check that the power LED is on and the contact status LED matches the switching state.

Maintenance: Conduct monthly visual inspections of LED status and terminal tightness. Test contact resistance annually using a multimeter; replace the relay if the resistance exceeds 100mΩ. Clean the DIN - rail and terminals regularly to prevent dust accumulation and poor contact.

Fault Diagnosis: No power LED indicates coil power failure; check the power supply and wiring. Unresponsive contacts may be due to coil burnout or contact welding; use a multimeter to measure coil resistance (normal range: 10 - 15kΩ) and replace the relay if faulty.
