ABB ECPSR086370-001 | ECPSR R.O. ±15V Power Supply Board

Reliable ±15V DC Power Supply Board for ABB QCS/DCS Control Systems

1. Product Overview

The ABB ECPSR086370-001 is an ECPSR R.O. (Regulated Output) ±15V power supply board, a dedicated power module for ABB QCS (Quality Control System) and DCS (Distributed Control System) equipment. It is designed to convert input power into stable ±15V DC regulated output, providing reliable power for core control modules, signal processing circuits, and analog I/O components in industrial automation systems. With overvoltage, overcurrent, and short-circuit protection functions, it ensures continuous and stable operation of the system even in harsh industrial environments, making it an essential component for maintaining the reliability and accuracy of paper-making, power generation, and other industrial processes.

ECPSR086370-001 -3.jpg

Key Specifications

• Manufacturer: ABB

• Model: ECPSR086370-001 (086370-001)

• Product Line: ABB QCS/DCS Power Supply

• Product Type: ECPSR R.O. ±15V Power Supply Board

• Input Voltage: 100-240 VAC (50/60 Hz)

• Output Voltage: +15 VDC, -15 VDC (Regulated)

• Output Current: +15V/2A, -15V/1A

• Protection Functions: Overvoltage, Overcurrent, Short-Circuit Protection

• Operating Temperature: -25°C to 70°C

• Storage Temperature: -40°C to 85°C

• Power Consumption: 30 Watts (Max)

• Mounting: DIN Rail or Chassis Mount (ABB QCS/DCS Standard)

• LED Indicators: Power OK, Overvoltage Fault, Overcurrent Fault

• Certifications: CE, UL Compliant

2. Core Features

• Stable Regulated Output: ±15V DC regulated output with low ripple and noise for precise signal processing and control operations.

• Comprehensive Protection: Overvoltage, overcurrent, and short-circuit protection to prevent damage to connected modules and ensure system safety.

• Wide Input Voltage Range: 100-240 VAC input compatible with global power grids for flexible installation in various industrial locations.

• Visual Status Monitoring: LED indicators for power status and fault conditions enable quick troubleshooting and system maintenance.

• Industrial-Grade Reliability: Robust design suitable for harsh industrial environments with stable performance in extreme temperatures and voltage fluctuations.

3. Typical Applications

• ABB QCS (Quality Control System): Powers core control modules, sensor interfaces, and data processing units in paper-making machines.

• Industrial DCS: Provides stable ±15V power for analog I/O modules, signal conditioners, and controller circuits in distributed control systems.

• Process Automation: Supports power supply for control systems in chemical, petrochemical, and water treatment plants.

• Power Generation: Supplies power to monitoring and control equipment in thermal power plants, hydropower stations, and renewable energy systems.

• Manufacturing: Powers precision control components in textile, printing, and packaging machinery for consistent product quality.

ECPSR086370-001 -4.jpg

4. Installation & Maintenance

Installation: Mount on DIN rail or ABB QCS/DCS chassis; connect 100-240 VAC input power; wire +15V and -15V output to connected modules; ensure proper grounding for electrical safety.

Maintenance: Regularly check LED indicators for power and fault status; inspect wiring connections for tightness and corrosion; verify output voltage stability with a multimeter; replace faulty modules to prevent system downtime.

Fault Diagnosis: Use LED indicators to identify overvoltage/overcurrent/short-circuit faults; check input power stability; test output voltage for deviation from ±15V; inspect protection circuits for proper operation.
