FBM242 RH916TA | 16-Channel Isolated Discrete Output Module--KIMI

Part number：FOXBORO FBM242 RH916TA
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

FOXBORO FBM242 RH916TA | 16-Channel Isolated Discrete Output Module for I/A Series/Evo DCS

16-Channel Galvanically Isolated Discrete Output Switch for Precise Control of Valves, Motors, and Actuators in Process Automation

1. Product Overview

The FOXBORO FBM242 RH916TA is a 16-channel isolated discrete output module for Foxboro I/A Series and Evo DCS, designed to convert digital control signals from the DCS controller into high-power switching outputs for field devices (valves, motors, pumps, and actuators) via external power sources. Each channel features 2500V AC galvanic isolation (channel-to-channel and channel-to-ground) to prevent cross-talk and surge damage, supporting 15-60VDC (2A max), 120VAC/125VDC, and 240VAC loads with solid-state or relay switching options. The module operates on 24VDC (8W max power), offers -20°C to +70°C wide temperature range, and includes LED status indicators for each channel, ensuring reliable operation in harsh industrial environments (oil/gas, chemical, power, water/wastewater) with ATEX Zone 2 and UL Class 1, Div 2 compliance for safety and EMC immunity.

FOXBORO FBM242 RH916TA (9).jpg

Key Specifications

• Model: FBM242 (Order Code: RH916TA)

• Type: 16-Channel Isolated Discrete Output Module (External Source Switch) for Foxboro I/A Series/Evo DCS

• Output Channels: 16 independent channels, solid-state or relay switching (external power)

• Load Compatibility: 15-60VDC (2A max per channel), 120VAC/125VDC, 240VAC (5A max per channel)

• Isolation: 2500V AC channel-to-channel and channel-to-ground (1 minute)

• Communication: Redundant 2 Mbps module Fieldbus for real-time data exchange with DCS controller

• Power Supply: 24VDC (±10%), 8W max power consumption (SELV/Limited Energy)

• Operating Temperature: -20°C to +70°C; Storage: -40°C to +85°C

• Protection Rating: IP20 rear terminals; ATEX Zone 2, UL Class 1, Div 2 (hazardous area)

• Dimensions (W×H×D): 104mm × 45mm × 114mm; Weight: ~0.35kg

• Certifications: ATEX II 3G Ex nA IIC T4 Gc, UL 61010-1, IEC 61326-1 (EMC)

• Diagnostics: LED indicators per channel (ON/OFF/Fault); Fail-Safe output configuration

FOXBORO FBM242 RH916TA (11).jpg

2. Core Features

• 16 Independent Isolated Channels: 2500V AC isolation prevents electrical interference and surge damage in industrial environments.

• Flexible Load Support: Compatible with 15-60VDC, 120VAC/125VDC, and 240VAC loads for diverse field device control.

• Redundant Communication: 2 Mbps module Fieldbus with redundancy ensures continuous data transmission and system availability.

• Fail-Safe Configuration: Outputs can be set to safe state (ON/OFF) during power loss or communication failure for process safety.

• Hot-Swappable Design: Easy removal/replacement without disconnecting field wiring, power, or communication cables.

• LED Status Indicators: Individual channel LEDs for ON/OFF/Fault to simplify troubleshooting and maintenance.

• Wide Temperature Range: -20°C to +70°C for reliable operation in extreme industrial conditions.

• Hazardous Area Compliance: ATEX Zone 2 and UL Class 1, Div 2 certification for safe use in explosive environments.

FOXBORO FBM242 RH916TA (10).jpg

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Oil & Gas: Wellhead valve control (240VAC actuators); pump start/stop (120VAC contactors) with fail-safe shutdown.

• Chemical Processing: Reactor feed valve actuation (60VDC solenoids); batch process sequencing (24VDC relays).

• Power Generation: Boiler feedwater pump control (240VAC motors); turbine lube oil system valves (125VDC solenoids).

• Water/Wastewater: Sewage treatment plant aerator control (120VAC motors); chemical dosing pump switching (24VDC relays).

• Pulp & Paper: Paper machine section drive control (240VAC VFDs); steam valve actuation (60VDC solenoids).

FOXBORO FBM242 RH916TA (1).jpg

4. Installation & Maintenance

Installation: Mount on Foxboro I/A Series I/O rack; connect 24VDC power (reverse-polarity protected). Wire external power (15-60VDC/120VAC/240VAC) and field devices to terminal assembly (TA). Verify insulation resistance (>100MΩ) before power-up.

Configuration: Use Foxboro Control Builder to set output mode (solid-state/relay), fail-safe state (ON/OFF), and channel mapping to DCS control logic.

Maintenance: Monthly: Inspect terminal connections; check LED status for fault indication. Annual: Test isolation resistance; replace module if channel fault persists after troubleshooting.

Fault Diagnosis: Channel fault = Check external power, load, and wiring; Communication loss = Verify Fieldbus connection and DCS controller status.
