Foxboro PSFLT-B2S0151 + IDP10-AF1C01F Differential Pressure Transmitter--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Foxboro PSFLT-B2S0151 + IDP10-AF1C01F Differential Pressure Transmitter
I/A Series Two - Wire Intelligent D/P Cell Transmitter with Filter Assembly for Industrial Process Control
1. Product Overview
The Foxboro PSFLT - B2S0151 + IDP10 - AF1C01F is a combined differential pressure measurement solution consisting of the IDP10 - AF1C01F intelligent two - wire d/p Cell transmitter and PSFLT - B2S0151 process filter assembly, belonging to Foxboro's I/A Series (now under Schneider Electric). It accurately measures differential pressure in industrial processes and converts it into a 4-20mA standard current signal with superimposed HART digital communication for remote configuration and monitoring. The filter assembly effectively protects the transmitter's sensor from process media impurities, ensuring long - term stable operation. It is widely used in liquid level, flow, and pressure measurement in industries such as petrochemicals, power generation, and water treatment, with high accuracy, long - term stability, and explosion - proof options.
2. Key Technical Specifications
• Product Combination: IDP10 - AF1C01F (Transmitter)+PSFLT - B2S0151 (Filter Assembly)
• Brand & Model: Foxboro PSFLT - B2S0151 + IDP10 - AF1C01F (I/A Series)
• Product Type: Intelligent Differential Pressure Transmitter (Two - Wire)
• Core Function: Differential Pressure Measurement, 4-20mA + HART Signal Output
• Measurement Range: 0-75 mbar to 0-210 bar (Differential Pressure)
• Accuracy: 0.05% of Calibrated Span (Digital Linear Mode); 0.06% (4-20mA Linear Mode)
• Output Signal: 4-20mA DC + HART (Software Selectable FoxCom/FF H1)
• Power Supply: Two - Wire Loop Power (12-42 VDC)
• Filter Function: PSFLT - B2S0151 Removes Process Media Impurities
• Process Connection: 1/4 NPT (Standard); Flange Options Available
• Material: 316L Stainless Steel (Wetted Parts); Aluminum Alloy/316 Stainless Steel Housing
• Protection Class: NEMA 4X / IP66
• Operating Temperature: -29°C to +82°C (-20°F to +180°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Certifications: ATEX, IECEx, FM, CSA, CE, HART Registered
• Warranty: 5 Years (Foxboro Standard)
3. Core Features
• High Accuracy: Advanced silicon strain gauge sensor technology ensures precise measurements.
• Filter Protection: PSFLT - B2S0151 Filter Assembly Prevents Sensor Contamination.
• HART Communication: Remote Configuration, Calibration, and Diagnostics via HART Protocol.
• Long - Term Stability: Drift < 0.05% of Span per Year for Reliable Long - Term Operation.
• Versatile Mounting: Direct Process Mounting or Remote Seal Installation.
• Explosion - Proof Options: Suitable for Hazardous Areas (ATEX/IECEx Certified).
• Modular Design: Easy Maintenance and Spare Parts Replacement.
• Wide Compatibility: Works with Most DCS/PLC Systems (Siemens, Rockwell, etc.).
4. Typical Applications
• Petrochemical: Distillation Column Liquid Level Measurement, Pipeline Flow Monitoring.
• Power Generation: Boiler Drum Level Control, Steam Flow Measurement.
• Water Treatment: Filter Differential Pressure Monitoring, Water Tank Level Measurement.
• Chemical Industry: Reactor Pressure Difference Monitoring, Material Flow Control.
• Oil & Gas: Wellhead Pressure Monitoring, Pipeline Leak Detection.
• Food & Beverage: Sanitary Process Pressure/Differential Pressure Measurement.
5. Installation & Maintenance
• Mounting: Direct Process Mounting or 2" Pipe Mounting (Bracket Included).
• Filter Installation: Connect PSFLT - B2S0151 Between Process Pipeline and Transmitter Inlet.
• Wiring: Two - Wire Loop Connection (No Polarity Requirement for 4-20mA).
• Configuration: Use HART Communicator (e.g., Rosemount 475) for Range/Unit Setting.
• Maintenance: Regularly Clean PSFLT - B2S0151 Filter; Check HART Communication Status.
• Troubleshooting: Use HART Diagnostics to Identify Sensor/Communication Faults; Inspect Filter Blockage.
• Safety Guidelines: Follow Explosion - Proof Area Operation Rules; Use ESD Protection During Servicing.
Technical Document | Foxboro PSFLT - B2S0151 + IDP10 - AF1C01F | Differential Pressure Transmitter | Industrial Process Control
