Foxboro FBM232 P0926GW Ethernet Communication Module--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Foxboro FBM232 P0926GW Ethernet Communication Module
10/100 Mbps Ethernet Interface for Foxboro I/A Series DCS
1. Product Overview
The Foxboro FBM232 P0926GW is a 10/100 Mbps Ethernet communication module for the Foxboro I/A Series distributed control system (DCS), designed to connect field devices to the DCS via Ethernet networks. It supports Modbus TCP/IP protocol, enabling cyclic and acyclic data exchange with up to 64 external devices, and integrates seamlessly with Foxboro's control environment. With dual 48-pin connectors, LED status indicators, and industrial-grade design, it ensures reliable data transmission in harsh industrial settings, making it ideal for process automation, power generation, oil & gas, and manufacturing applications.
Key Specifications
• Model: FBM232 | Part Number: P0926GW | Brand: Foxboro (Schneider Electric) | Series: I/A Series
• Type: Ethernet Communication Module (10/100 Mbps, RJ45)
• Protocol: Modbus TCP/IP, DCI (Device Control Interface) block compatibility
• Data Rate: 10/100 Mbps (auto-negotiation), 10Base-T/100Base-TX
• Device Capacity: Up to 64 field devices via Ethernet switch/hub
• Power Supply: 24 VDC, Power Consumption: < 2 W
• Connectors: Dual 48-pin baseplate connectors, 1 x RJ45 Ethernet port
• Indicators: Power (Green), Status (Amber), Fault (Red), Link/Activity (Green)
• Operating Temperature: -40°C to +70°C; Storage Temperature: -40°C to +85°C
• Humidity: 5-95% (non-condensing); Protection Class: IP20 (module), IP30 (with baseplate)
• Certifications: CE, UL, RoHS Compliant
• Dimensions: 110 mm (W) × 115 mm (H) × 45 mm (D); Weight: 0.34 kg
2. Core Features
• High-Speed Ethernet: 10/100 Mbps auto-sensing for flexible network integration
• Modbus TCP/IP Support: Enables seamless data exchange with Modbus-enabled devices
• DCI Block Compatibility: Supports up to 2000 DCI blocks for device control and monitoring
• LED Status Monitoring: Real-time indication of power, communication, and fault conditions
• Industrial-Grade Durability: Wide temperature range and vibration resistance for harsh environments
• Plug-and-Play Integration: Works with Foxboro I/A Series baseplates (P0916TA/P0916TB) for easy installation
• Redundant Network Ready: Compatible with dual Ethernet setups for high availability
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Process Automation: Oil & gas refineries, chemical plants, and water/wastewater treatment DCS integration
• Power Generation: Connect I/A Series DCS to turbine controls, generators, and auxiliary systems
• Manufacturing: Automate production lines with Ethernet-enabled sensors, drives, and remote I/O
• Pharmaceutical: Comply with 21 CFR Part 11 via secure data logging and device control
• Marine: Integrate shipboard systems (pumps, valves, instrumentation) with I/A Series DCS
4. Installation & Maintenance
Installation: Mount on P0916TA/P0916TB baseplate; Connect 24 VDC power; Wire Ethernet (CAT5e/CAT6, max 100m); Configure via Foxboro I/A Series Engineering Tools.
Maintenance: Daily – Check LED indicators (Power, Status, Fault, Link/Activity); Weekly – Verify data consistency and network latency; Annual – Inspect wiring, clean dust, update firmware.
Safety Notes: Use ESD wrist strap during handling; De-energize power before module replacement; Follow Ethernet installation guidelines for shielding and grounding.
