Foxboro P92 P9220436070H 24V DC Industrial Power Supply Module--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

Foxboro P92 P9220436070H 24V DC Industrial Power Supply Module

Redundant Power Supply Module for Foxboro DCS Field Control Units, Ensuring Stable Power for Critical Process Control

1. Product Overview

The Foxboro P92 P9220436070H is a 24V DC industrial power supply module designed for Foxboro (Schneider Electric) DCS systems, providing redundant, stable power for field control processors, I/O modules, and communication interfaces in industrial automation. With 24V DC input/output, 10A maximum output current, dual‑channel redundancy, and comprehensive protection (over‑voltage, over‑current, short‑circuit), it ensures reliable operation in harsh industrial environments like chemical, oil & gas, power generation, and pulp & paper. The module features a compact design, wide operating temperature range, and seamless integration with Foxboro P92 workstation/DCS cabinets, ideal for critical process control requiring high availability.

P92 P9220436070H -1.jpg

2. Key Technical Specifications

• Product Type: 24V DC Industrial Power Supply Module (Redundant, DCS‑Compatible)

• Brand & Model: Foxboro P92 P9220436070H (P92 Series, Schneider Electric)

• Input Voltage: 24V DC (Redundant Input Channels, 18‑36V DC Operating Range)

• Output Voltage: 24V DC (Adjustable ±5%)

• Maximum Output Current: 10A (Continuous)

• Power Efficiency: ≥90% (Typical, Full Load)

• Redundancy: Dual‑Channel Redundant Design (Automatic Failover)

• Protection Features: Over‑Voltage, Over‑Current, Short‑Circuit, Reverse Polarity Protection

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)

• Storage Temperature: -40°C to +85°C (-40°F to +185°F)

• Humidity: 5% - 95% RH (Non‑Condensing)

• Dimensions: 100 × 50 × 20 mm (3.94 × 1.97 × 0.79 in)

• Weight: 0.1 kg (0.22 lbs)

• Mounting: DIN Rail Mount (TS35 × 7.5) in P92 DCS Cabinets/Workstations

• Certification: CE, RoHS, UL 508 (Industrial Control Equipment Safety)

• MTBF: >100,000 Hours (Typical, at 25°C)

P92 P9220436070H -3.jpg

3. Core Features

• Redundant Power Design: Dual‑Input/Output Channels for 24/7 Operation in Critical DCS Applications.

• High Current Capacity: 10A Maximum Output to Power Multiple I/O Modules and Control Processors.

• Comprehensive Protection: Over‑Voltage, Over‑Current, Short‑Circuit, and Reverse Polarity Protection.

• Wide Temperature Range: -40°C to +70°C for Harsh Industrial Environment Compatibility.

• Compact Size: 100 × 50 × 20 mm, Saving Cabinet Space in DCS Installations.

• Easy Integration: Seamless Compatibility with Foxboro P92 Workstations and DCS Systems.

• LED Status Indicators: Power On, Fault, and Redundancy Status for Quick Monitoring.

P92 P9220436070H -4.jpg

4. Typical Applications

• Foxboro DCS Systems: Power for Field Control Processors (FCP), I/O Modules, and Communication Cards.

• Chemical Industry: Power for Reactor Control, Batch Process Automation, and Hazardous Area DCS.

• Oil & Gas: Offshore Platform DCS Power, Pipeline Monitoring System Power Supply.

• Power Generation: Boiler Control, Turbine Monitoring, and Distributed Control System Power.

• Pulp & Paper: Paper Machine Control, Chemical Dosing System Power, and Process Monitoring.

P92 P9220436070H -2.jpg

5. Installation & Maintenance

• Mounting: TS35 × 7.5 DIN Rail Mount in Foxboro P92 DCS Cabinets/Workstation Racks.

• Wiring: Redundant 24V DC Input (18‑36V DC), 24V DC Output to FCP/I/O Modules; Shielded Cables Recommended.

• Redundancy Setup: Connect Dual Power Inputs (A/B Channels) for Automatic Failover.

• Diagnostics: LED Indicators (Power, Fault, Redundancy) for Status Monitoring; Alarm Output for Remote Notification.

• Maintenance: Hot‑Swappable (Redundant Configurations); Replace Fuses (20A Slow‑Blow) for Short‑Circuit Protection.

• Troubleshooting: Use Foxboro I/A Series Engineering Tools for Power Module Health Monitoring.
