FOXBORO E69F-T-I2-JRS Product Brief Description
The FOXBORO E69F-T-I2-JRS is a field-mounted current-to-pneumatic (I/P) transducer belonging to the E69F series. It receives 4-20mA DC control signal from DCS or controllers and converts it proportionally to 3-15psi (0.2~1.0bar) pneumatic output to drive pneumatic valve actuators. This variant comes with customized certification and enclosure options for hazardous field locations, supporting direct/reverse action selection to meet diverse valve control requirements.
Product Features
- Field I/P converter, input 4-20mA DC, pneumatic output 3-15psi (0.2~1.0bar)
- Typical linearity ±0.5% span, repeatability ±0.25% span, stable control performance
- Weatherproof Type 4 enclosure, non-incendive certification for Class I Div 2 hazardous areas
- Supports direct or reverse action switching for different actuator configurations
- Zero and span adjustment accessible on site for calibration without full disassembly
- Robust construction with vibration resistance for continuous plant field operation
Application Scenarios
- Petrochemical and chemical plant pneumatic control valve signal conversion
- Oil & gas processing field actuator positioning and closed-loop regulation
- Power plant boiler auxiliary pneumatic control loops
- Pulp & paper, pharmaceutical process control valve actuation
- Legacy Foxboro I/A DCS field I/P transducer spare replacement and retrofit
Frequently Asked Questions
Q1: What is FOXBORO E69F-T-I2-JRS?
A1: It is a current-to-pneumatic I/P transducer, converting 4-20mA electrical control signal into 3-15psi pneumatic signal to operate pneumatic valve actuators in hazardous industrial sites.
Q2: What is the difference between E69F-T-I2-JRS and E69F-BI2-S?
A2: Both are E69F series I/P transducers. E69F-T-I2-JRS has different housing, certification and option codes for special hazardous area requirements, while maintaining the core 4-20mA to 3-15psi conversion function.
Q3: Can it switch direct and reverse action?
A3: Yes, direct or reverse action can be configured on site to match fail-open or fail-close control valves.
Q4: Is E69F-T-I2-JRS still in original production?
A4: This legacy I/P transducer is discontinued. We supply fully tested surplus/refurbished units. Contact sales for stock status and warranty terms.
