INDRAMAT 109-525-1252A Product Description

INDRAMAT 109-525-1252A (RC8 Brake Resistor Interface Board) is a plug-in auxiliary PCB for Indramat TDM series servo drive racks. It manages braking resistor switching, regenerative energy dissipation and thermal/overcurrent protection for servo axes. When the motor decelerates, the board activates the braking resistor to absorb regenerative energy and prevent DC bus overvoltage. It also handles internal signal exchange between the drive main control board and power stage. This legacy card is stocked as fully-tested spare hardware for CNC machine servo drive maintenance and replacement.

Product Features

• RC8 braking resistor control & interface board for Indramat TDM servo drives
• Controls switching of external braking resistors to absorb motor regenerative energy
• Prevents DC bus overvoltage during fast deceleration, emergency stop or rapid positioning
• Integrated thermal monitoring and overcurrent protection for braking resistors
• Signal interface channel for communication with drive main control PCB
• Plug-in card design for direct installation inside TDM servo drive rack slots
• Industrial EMC protection against electrical noise inside machine tool cabinets
• Onboard capacitors and relay components for reliable energy switching
• Wide operating temperature range, resistant to vibration and dust in CNC environments

Application Scenarios

• CNC machining centers with Indramat TDM servo drive systems
• Milling, grinding and boring machine servo axis dynamic braking control
• Automated assembly lines, robotics and high-speed positioning equipment
• Metal cutting machine tool servo drive cabinet overhaul and retrofit
• Emergency spare parts for TDM servo drives with frequent rapid deceleration cycles
• Replacement for legacy Rexroth Indramat RC8 braking interface assemblies
