Product Brief Description

The Rexroth Indramat DKR02.1-W200N-B is a single-axis digital spindle drive controller from the DKR02 series, rated for 200A continuous output current. It operates on 3×400–480V three-phase mains power and is engineered to drive Indramat spindle motors, frameless motors and linear motors for high-power CNC machinery. This base unit comes without additional option cards, supporting regenerative energy feedback back to the power grid and integrated emergency stop function, widely used as replacement spare part for legacy machine tool automation systems.

Product Features & Functions

• Single axis spindle drive, 200A continuous output current, 400~480V three-phase AC input
• Digital closed-loop control for speed, torque and position of spindle and linear motors
• Integrated mains contactor and built-in emergency stop safety shutdown circuit
• Regenerative braking design feeds back motor kinetic energy directly to the mains
• Supports resolver and digital encoder feedback for high-precision motor commutation
• Comprehensive fault monitoring: overcurrent, overvoltage, overtemperature and short-circuit protection
• Rack mount design, built-in blower cooling, wide constant-power speed range for spindle applications

Application Scenarios

• Heavy-duty CNC machine tools, milling machines and machining center spindle control
• Printing machinery, paper processing and high-speed industrial automation equipment
• Linear motor motion platforms and frameless spindle motor drive systems
• Metal forming, woodworking and textile high-power spindle automation
• Legacy Indramat DKR series drive maintenance, retrofit and spare replacement
