Product Brief Description

The Bosch Rexroth VT-TSPD-1-10/V0/Q is a rack-mounted digital servo valve amplifier board for closed-loop hydraulic control. It receives setpoint signals from the main controller and outputs precise drive current for Rexroth proportional and servo valves, supporting high dynamic closed-loop regulation of pressure, flow and position. The /Q variant features enhanced quality screening for demanding continuous-duty hydraulic machinery, widely used as a critical spare part for industrial hydraulic control cabinets.

Product Features & Functions

• Digital closed-loop drive for Rexroth hydraulic servo and proportional valves
• Accepts analog command signals for position, pressure and velocity control loops
• Onboard parameter configuration, gain tuning and valve characteristic compensation
• Built-in fault diagnostics for coil short circuit, wire break and signal failure
• High EMC immunity design to suppress noise in high-power hydraulic cabinet environments
• Standard Eurocard rack mounting form factor for quick installation and replacement
• 24VDC power supply, CE compliance for global industrial automation applications

Application Scenarios

• High-speed hydraulic presses and metal forming machinery
• Plastic injection molding, die casting and blow molding equipment
• Material fatigue test benches and hydraulic simulation systems
• Steel mill rolling lines, bending machines and heavy machine tools
• Hydraulic system upgrade, maintenance and spare part replacement
