INDRAMAT 109-525-3201A-8 Product Description

INDRAMAT 109-525-3201A-8 is a memory / program expansion board for Rexroth Indramat TDM servo drive controller racks. This plug-in PCB extends the onboard memory storage of the TDM main control board (such as 109-525-2237A-3), used to store motion programs, axis parameter sets, position profiles and firmware data. It communicates via the rack backplane with the main servo CPU, enabling larger program capacity for multi-axis CNC and automation applications. Conformal coated for workshop environments, this legacy board is stocked as fully tested spare hardware for TDM servo system maintenance and upgrade replacement.

Product Features

• Memory expansion card for Indramat TDM servo controller rack
• Stores CNC motion programs, axis parameters, position tables and system firmware
• Backplane communication interface to exchange data with TDM main control CPU
• Plug-in slot mounting design for easy installation inside TDM servo rack
• Conformal coated PCB for protection against oil mist, dust and vibration
• Gold-plated edge connector for stable backplane signal transmission
• 24VDC control power supply, low power consumption
• Onboard status LEDs to verify memory access and board operation
• High EMC noise immunity for machine tool cabinet environments

Application Scenarios

• CNC machining centers using Indramat TDM multi-axis servo racks
• Milling, boring and grinding machines requiring large motion program storage
• Automated assembly lines, robotic positioning and packaging machinery
• Metal cutting machine tool legacy TDM servo system retrofit
• System upgrade for expanded program capacity on existing TDM controllers
• Spare replacement when original memory expansion board fails or data corruption occurs
