Product: IS200AEPAH1BKE – GE Mark VI AEPA Analog Process I/O Board
GE IS200AEPAH1BKE | AEPA High Precision Analog Signal Processing Card for Speedtronic Mark VI Turbine Control System
IS200AEPAH1BKE is the full assembly revision of GE AEPA analog process I/O board under the Speedtronic Mark VI IS200 platform, suffix BKE represents hardware revision B, functional revision K, artwork revision E. It is a core multi-channel analog signal acquisition & conditioning board dedicated to gas/steam turbines and generator EX2100 excitation systems, responsible for collecting field 4–20mA, 0–10V analog signals from pressure, temperature, vibration, flow and LVDT valve position transmitters, with built-in high-precision A/D conversion, signal filtering and linearization algorithms. The board integrates 12 groups of auxiliary relay outputs for alarm interlock and threshold trip signals, supports simplex, dual redundant and TMR triple modular redundant architectures, and communicates with the main controller via high-speed redundant IONet backplane bus.
Core Technical Specifications
- Part Number: IS200AEPAH1BKE | Abbreviation: AEPA | Brand: General Electric | Series: Speedtronic Mark VI IS200 VME Rack
- Signal Channels: 8 multi-range isolated analog input channels (4–20mA / 0–5V / 0–10V configurable per channel)
- Relay Output: 12 built-in SPDT programmable alarm/trip relays for unit interlock signal output
- A/D Conversion: 16-bit high-resolution ADC, full-scale measurement accuracy ≤ ±0.1%FS
- Onboard Connectors: Total 19 multi-pin vertical plug terminals for field wiring, backplane bus and auxiliary daughterboard docking
- Redundancy Support: Compatible with simplex, dual redundant and TMR triple modular safety architectures
- Backplane Communication: Redundant IONet high-speed bus, microsecond-level real-time data polling cycle
- Rack Power Supply: +5VDC logic power, ±15VDC analog reference power supplied by Mark VI VME backplane
- PCB Protection: Full conformal coating, anti-dust, moisture and corrosive gas for power plant cabinet environments
- Operating Temperature: -20°C ~ +70°C | Storage Temperature: -40°C ~ +85°C
- Anti-Surge Design: 6 built-in metal oxide varistors (MOV) to suppress transient high voltage interference
- Certifications: CE, UL, IEC 61508 SIL2 functional safety compliance, industrial EMC anti-interference standard
- Dimension & Weight: 210×160×35mm, net weight approx. 0.9kg
Main Functional Features
- Multi-channel independent signal conditioning, each channel equipped with configurable digital filter (0.01s–10s time constant) and cold-end compensation for temperature sensors
- Built-in sensor linearization algorithm, automatic correction for thermocouple, RTD and LVDT non-linear output signals
- 12 programmable relay outputs, freely linked to over-limit, sensor fault and system abnormal alarm logic for turbine safety interlock
- Complete channel self-diagnosis system, real-time detection of transmitter open circuit, short circuit, signal over-range and board power failure faults
- Supports hot-swap replacement under redundant rack configuration, no full unit shutdown required during maintenance to reduce power generation downtime
- Dual auxiliary daughterboard docking interface, expand extra analog I/O and trip signal channels according to on-site control demands
- Hardware surge suppression circuit, effectively isolate high-frequency EMI interference from high-voltage excitation and medium voltage drive cabinets
- Fully compatible with ToolboxST Mark VI configuration software, support channel range calibration, alarm threshold setting, fault waveform recording and firmware online upgrade
Application Industries
- Combined Cycle & Thermal Power Plant: Mark VI gas/steam turbine main control cabinet analog signal acquisition & alarm interlock unit
- Hydropower Station: Large generator EX2100 excitation regulator pressure, temperature and valve position monitoring board
- Oil & Gas Industry: Offshore platform and gathering station turbine generator vibration and process parameter monitoring rack
- Industrial Cogeneration Station: Reciprocating engine generator set safety trip analog signal processing equipment
- Equipment Retrofit & Maintenance: Spare replacement for aging Mark VI turbine control analog I/O modules
