1. Product Overview
The ABB PFEA111-65 (order code: 3BSE028140R0065) is a dual-channel tension measurement and control unit designed for industrial web, wire, cable, and metal processing applications. It integrates high-precision signal conditioning, real-time tension calculation (A, B, A+B, A-B modes), and analog output (0-10V/4-20mA) for closed-loop control of motors, brakes, or clutches. The unit supports two load cell inputs (strain gauge/piezoelectric), Profibus DP/Modbus RTU communication, and an IP65/NEMA 4 front panel for harsh industrial environments. With a 24VDC power supply (8W max), 0.1% measurement accuracy, and a response time of<10ms, it ensures consistent tension in dynamic processes, reducing material waste and improving product quality in textiles, paper, plastics, metalworking, and cable manufacturing.
Product ID:3BSE050090R65
ABB model name :PFEA111-65
Catalogue Description :Tension Electronics PFEA111-65
Change product ID (OLD) :3BSE028140R65
Technical information
2 Load Cells Input, Voltage and Current
Output A+B with adjustable
filtering. Shown on display A, B, A+B, A-B
PFEA111-65, Incl. a CD user manual
Key Specifications
• Manufacturer: ABB (Tension Electronics Series)
• Model: PFEA111-65 (Order Code: 3BSE028140R0065)
• Input Channels: 2 load cell inputs (strain gauge/piezoelectric, 3mV/V sensitivity)
• Measurement Modes: A, B, A+B (sum), A-B (difference) for real-time tension monitoring
• Output Signals: 0-10V voltage (12-bit), 4-20mA current (12-bit); 2 relay outputs (250VAC/5A)
• Communication: Profibus DP (optional), Modbus RTU (RS485); baud rate up to 115.2 kbps
• Power Supply: 24VDC (±20%), 8W max power consumption
• Accuracy: ±0.1% of full scale; Response Time:<10ms
• Protection Rating: IP65 front panel (NEMA 4), IP20 rear terminals
• Operating Temperature: -40°C to +70°C (wide temp); 0°C to +60°C (standard)
• Dimensions (W×H×D): 122mm × 96mm × 60mm; Weight: ~0.5kg
• Certifications: CE, UL 61010-1, IEC 61326-1 (EMC)
2. Core Features
• Dual-Channel Precision: 2 load cell inputs with 0.1% accuracy for real-time tension measurement in sum/difference modes.
• Fast Response:<10ms signal processing for dynamic tension control in high-speed lines (up to 1000m/min).
• Flexible Outputs: 0-10V/4-20mA analog outputs and relay contacts for direct control of brakes, clutches, or VFDs.
• Communication Integration: Profibus DP/Modbus RTU for seamless PLC/SCADA connectivity and remote parameterization.
• Harsh Environment Ready: IP65 front panel (dust/waterproof) and wide temp range (-40°C to +70°C) for outdoor/industrial use.
• User-Friendly Interface: 4-digit LED display with push-button calibration; configurable filter (0.1Hz to 100kHz) for noise reduction.
• Advanced Diagnostics: Built-in fault detection (overload, open load cell, communication error) with visual/audio alerts.
• Energy Efficient: 24VDC, 8W max power consumption for cost-effective operation.
