CI930F 3BDH001010R0005 PROFIBUS DP Master Module--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB CI930F 3BDH001010R0005 PROFIBUS DP Master Module
High-Speed PROFIBUS DP Master with Redundancy for AC 900F Controllers
1. Product Overview
The ABB CI930F (3BDH001010R0005) is a high-performance PROFIBUS DP master module designed for seamless integration with ABB AC 900F controllers, supporting PROFIBUS DP V0/V1 protocols and line redundancy for critical industrial communication. It offers data rates up to 12 Mbps, dual 9-pin D-Sub ports for redundant lines A/B, and manages up to 126 slave devices per port, ensuring reliable real-time data exchange in process automation, manufacturing, and infrastructure projects. With industrial-grade durability, integrated diagnostics, and compatibility with AC 900F systems, it delivers stable operation in harsh industrial environments, minimizing downtime and enhancing system availability.
Key Specifications
• Model: CI930F | Part Number: 3BDH001010R0005 | Brand: ABB | Series: AC 900F Communication Module
• Type: PROFIBUS DP Master Module (supports DP-V0/V1 protocols)
• Data Rate: 9.6 kbps to 12 Mbps (auto-negotiation for DP networks)
• Device Capacity: Up to 126 PROFIBUS DP slave devices per port
• Redundancy: PROFIBUS line redundancy (dual ports A/B for seamless failover)
• Power Supply: 24 VDC (18–32 V range), Power Consumption: ~5 W
• Connectors: 2 x PROFIBUS DP (9-pin D-Sub), 1 x 24 VDC power terminal
• Indicators: Power (Green), Port A Status (Amber), Port B Status (Amber), Fault (Red)
• Operating Temperature: -25°C to +70°C; Storage Temperature: -40°C to +85°C
• Humidity: 5-95% (non-condensing); Protection Class: IP20 (module)
• Certifications: CE, UL, RoHS Compliant
• Dimensions: 220 mm (W) × 135 mm (H) × 35 mm (D); Weight: 0.15 kg
• Compatibility: ABB AC 900F Controller, AC 800M DCS, S800 I/O Systems
2. Core Features
• Line Redundancy: Dual PROFIBUS ports (A/B) ensure continuous communication during line failures
• High-Speed Data Transfer: 12 Mbps max rate for real-time control and monitoring
• Multi-Slave Management: Supports up to 126 slaves per port for scalable system integration
• Integrated Diagnostics: LED indicators for power, port status, and faults enable fast troubleshooting
• Industrial-Grade Design: -25°C to +70°C wide temperature range, vibration/shock resistance
• Easy Configuration: Compatible with ABB Control Builder F for intuitive programming and monitoring
• AC 900F Compatibility: Seamless integration with AC 900F controllers for unified system management
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Process Automation: Chemical plants, refineries, and batch process control
• Manufacturing: Production lines, robotics, and machine tool integration
• Infrastructure: Water treatment, pipeline monitoring, and power distribution
• Energy: Power generation, turbine control, and substation automation
• Building Automation: HVAC systems, access control, and facility management
4. Installation & Maintenance
Installation: Mount on standard DIN rail; Connect 24 VDC power; Wire PROFIBUS DP lines A/B (shielded twisted pair); Configure via Control Builder F.
Maintenance: Daily – Check LED indicators (Power, Port A/B Status, Fault); Weekly – Verify communication and data consistency; Annual – Inspect wiring, clean dust, update firmware.
Safety Notes: Use ESD protection during handling; De-energize power before module replacement; Follow PROFIBUS installation guidelines for shielding and grounding.
