PM902F 3BDH001000R0005 Main Controller Module-KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB PM902F 3BDH001000R0005 Main Controller Module
Core CPU Module for ABB AC 900F Industrial Process Control System
1. Product Overview
The ABB PM902F 3BDH001000R0005 is the core main controller (CPU) module of the ABB AC 900F distributed process control system, engineered for high-performance, high-reliability industrial process control. Equipped with a 32-bit RISC high-speed processor and large-capacity on-board memory, it supports redundant hot standby configuration, real-time multi-tasking operation, and seamless integration with ABB FI/FO I/O modules and communication modules (e.g., CI930F). It complies with IEC 61131-3 programming standards, supports multiple industrial fieldbus protocols, and delivers stable and precise control for continuous and batch processes in harsh industrial environments, making it the core control unit for oil & gas, petrochemical, power generation, and manufacturing automation systems.
Key Specifications
• Model: PM902F | Part Number: 3BDH001000R0005 | Brand: ABB | Series: AC 900F Control System
• Type: Main CPU Controller Module for Distributed Process Control
• Processor: 32-bit High-Speed RISC Processor, 200MHz core frequency
• Memory: 512MB Flash (firmware/configuration), 256MB SDRAM (real-time data/tasks)
• Redundancy: 1:1 hot standby redundant configuration,<10ms switchover time
• Programming Standard: IEC 61131-3 (LD, FBD, ST, IL, SFC)
• I/O Connectivity: FBP bus (Field Bus Peripheral), max 256 FI/FO I/O modules, 8192 I/O points
• Communication Interfaces: 2 x Ethernet (10/100Mbps, for system/engineering), 1 x FBP bus port
• Supported Protocols: Modbus TCP/IP, PROFIBUS DP, OPC UA, Ethernet/IP (via expansion)
• Power Supply: 24VDC (18-32VDC wide range), typical power consumption: 8W
• Operating Temperature: -25°C to +70°C; Storage Temperature: -40°C to +85°C
• Humidity: 5-95% (non-condensing); Vibration Resistance: 5-150Hz, 2g
• Protection Class: IP20 (module); MTBF: >1,000,000 hours
• Certifications: CE, UL, ATEX, IEC 61508 (SIL 2), RoHS Compliant
• Dimensions: 145mm (H) × 110mm (W) × 45mm (D); Weight: 0.65kg
• Compatibility: AC 900F rack, CI930F/CI854K01, FI/FO I/O modules, Control Builder F
2. Core Features
• High-Performance Processing: 200MHz 32-bit RISC CPU enables fast execution of complex control algorithms (PID, cascade, ratio control)
• Redundant Hot Standby: 1:1 redundant configuration with ultra-fast switchover, no process interruption during fault
• Large-Scale I/O Expansion: FBP bus supports up to 8192 I/O points, adaptable to large-scale industrial process control
• Standardized Programming: IEC 61131-3 compliance for flexible and easy program development and maintenance
• Multi-Protocol Communication: Seamless connection with fieldbus and industrial Ethernet, easy system integration
• Real-Time Multi-Tasking: Preemptive real-time operating system, guaranteed real-time performance of critical control tasks
• Industrial-Grade Reliability: Wide temperature range, vibration/shock resistance, MTBF over 1 million hours
• Online Maintenance: Hot-swappable design, module replacement without system shutdown
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Oil & Gas: Offshore platform process control, pipeline transportation, refinery production line control
• Petrochemical: Reactor temperature/pressure control, distillation unit automation, batch process control
• Power Generation: Thermal power plant auxiliary system control, gas turbine control, renewable energy station automation
• Manufacturing: Chemical fiber/paper production line control, metallurgical process automation, food and beverage batching
• Water & Wastewater: Large-scale water treatment plant process control, sewage treatment automation system
4. Installation & Maintenance
Installation: Mount on AC 900F standard rack; Connect 24VDC power supply; Wire FBP bus and Ethernet cables; Complete hardware configuration via Control Builder F; Set up redundant parameters for hot standby mode.
Maintenance: Daily – Check LED status (Power:Green, Run:Green, Redundancy:Amber, Fault:Red); Weekly – Verify CPU load, memory usage and communication status; Annual – Inspect module connections, clean dust, update firmware and Control Builder F.
Safety Notes: Use ESD wrist strap during handling and installation; De-energize power for initial wiring (hot-swappable for later replacement); Follow ABB safety guidelines for redundant system configuration and testing.
Technical Document | 3BDH001000R0005 | PM902F AC 900F Main Controller Module
