CI854K01 3BSE025961R1 AC800M DCS--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB CI854K01 3BSE025961R1 PROFIBUS DP‑V1 Interface Kit
High‑Performance Communication Interface for ABB AC800M DCS
1. Product Overview
The ABB CI854K01 (3BSE025961R1) is a PROFIBUS DP‑V1 interface kit designed for seamless integration between ABB AC800M controllers and PROFIBUS field devices. It includes the CI854 communication module and TP854 60mm baseplate, supporting master/slave operation with a maximum data transfer rate of 12 Mbps via RS‑485 interface. With integrated diagnostics, redundant network support, and industrial‑grade reliability, it enables real‑time data exchange and device control in process automation, power generation, oil & gas, and manufacturing industries, ensuring stable communication between DCS and field instruments, drives, and remote I/O.
Key Specifications
• Model: CI854K01 | Part Number: 3BSE025961R1 | Brand: ABB | Series: AC800M Communication
• Protocol: PROFIBUS DP, DP‑V1 (cyclic/acyclic data exchange)
• Interface: RS‑485, 1 channel, integrated termination resistor
• Data Rate: 9.6 kbps – 12 Mbps (auto‑negotiation)
• Operation Mode: Master/Slave, supports up to 120 nodes
• Power Supply: 24 VDC (1.2 W typical)
• Diagnostics: LED indicators (Power, Status, Fault, Communication), event logging
• Operating Temperature: -25°C to +70°C; Storage Temperature: -40°C to +85°C
• Humidity: 5–95% (non‑condensing); Protection Class: IP20 (module)
• Certifications: CE, UL, RoHS Compliant
• Dimensions: 177 mm (H) × 35 mm (W) × 145 mm (D); Weight: 0.5 kg
• Package: CI854 module + TP854 60mm baseplate
2. Core Features
• PROFIBUS DP‑V1 Support: Enables cyclic process data exchange and acyclic parameterization/diagnostics
• Master/Slave Flexibility: Configurable as PROFIBUS master for network control or slave for device integration
• Integrated Diagnostics: Real‑time status monitoring via LEDs and event logs for fast troubleshooting
• Redundant Network Ready: Compatible with dual‑network setups for high availability applications
• Plug‑and‑Play Integration: Works seamlessly with ABB 800xA engineering software for easy configuration
• Industrial‑Grade Reliability: Wide temperature range, vibration resistance, and long‑term stability
• Compact Design: 60mm baseplate saves rack space, ideal for dense DCS configurations
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Process Automation: Oil & gas refineries, chemical plants, and water treatment DCS integration
• Power Generation: Connect AC800M to turbine controls, generators, and auxiliary systems
• Manufacturing: Automate production lines with PROFIBUS‑enabled drives, sensors, and robots
• Infrastructure: Integrate HVAC, lighting, and security systems in building automation
• Marine: Control propulsion systems, pumps, and instrumentation on offshore platforms
4. Installation & Maintenance
Installation: Mount TP854 baseplate in AC800M rack; Insert CI854 module; Connect 24 VDC power; Wire PROFIBUS network (A/B lines + ground); Configure via 800xA Engineering Environment.
Maintenance: Daily – Check LED status (Power: Green, Status: Blue, Fault: Red); Weekly – Verify network communication and data consistency; Annual – Inspect wiring, clean dust, and update firmware.
Safety Notes: Use ESD protection during handling; De‑energize power before module replacement; Follow PROFIBUS installation guidelines for cable shielding and termination.
