ABB PU410 3BSE056478R1 RTA Communication Box--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB PU410 3BSE056478R1 RTA Communication Box
Real-Time Communication Terminal for ABB Advant OCS MB300 Controller
1. Product Overview
The ABB PU410 3BSE056478R1 is a Real-Time Accelerator (RTA) communication box specifically designed for the ABB Advant OCS system, serving as a critical communication terminal for the MB300 controller. It enables real-time data exchange between the MB300 controller and remote terminal units (RTUs), field devices, and upper-level monitoring systems. This module supports multiple industrial communication protocols, redundant Ethernet configuration, and industrial-grade environmental resistance, ensuring reliable data transmission and stable communication in harsh industrial environments. It is widely used in distributed control scenarios such as power plants, petrochemical complexes, and metallurgical facilities, facilitating seamless integration and remote monitoring of industrial processes while enhancing system operational efficiency and fault tolerance.
General Information
PU410
3BSE056478R1
PU410
Communication Box
2. Key Technical Specifications
• Brand & Model: ABB PU410 (Ordering Code: 3BSE056478R1)
• Product Type: RTA Communication Box for Advant OCS MB300 Controller
• Communication Protocols: Profibus DP, Modbus RTU/TCP, Ethernet TCP/IP
• Communication Channels: Dual - channel MB300 RTA interface, 2 x 10/100M Ethernet Ports (Redundant), 1 x Profibus DP Port
• Power Supply: 24V DC (±10%), Typical Power Consumption: 15W
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Relative Humidity: 5% - 95% (Non - Condensing)
• Redundancy Support: Redundant Ethernet Communication, Hot - Swap Compatible
• Net Weight: 0.39 kg
• Dimensions: 120mm × 100mm × 80mm (W×H×D)
• Installation: DIN Rail Mounting, Panel Mounting Optional
• Replacement Model: PU410K01 (3BSE051826R1, with Spare Fan)
• Certification: CE, UL, IEC 61010 - 1
3. Core Features
• Multi - Protocol Support: Compatible with Profibus DP, Modbus RTU/TCP, and Ethernet TCP/IP for flexible integration with diverse field devices.
• Redundant Communication: Dual Ethernet ports ensure communication continuity even if one link fails, improving system reliability.
• Real - Time Data Transmission: RTA technology guarantees low - latency and deterministic data exchange for time - sensitive control tasks.
• Industrial - Grade Durability: Withstands extreme temperatures, humidity, and electromagnetic interference in industrial settings.
• Hot - Swap Compatibility: Allows online replacement without disrupting system operation, reducing maintenance downtime.
• Seamless System Integration: Works perfectly with ABB Advant OCS and 800xA systems for unified monitoring and control.
• Comprehensive Diagnostics: Built - in diagnostic functions detect and report communication faults promptly for quick troubleshooting.
• Easy Installation: DIN rail mounting design simplifies on - site installation and space - saving arrangement.
4. Typical Applications
• Power Generation: Remote monitoring of thermal power plant auxiliary equipment, data transmission for hydropower station distributed control systems.
• Petrochemical Industry: Communication between refinery process control units and central control rooms, data sharing for chemical plant safety instrumented systems.
• Metallurgy: Real - time data exchange for iron and steel plant blast furnace control systems, communication between rolling mill drive systems and monitoring stations.
• Water & Wastewater: Data transmission for urban water supply network RTUs, communication for sewage treatment plant process control equipment.
• Oil & Gas: Communication between offshore platform control systems and on - shore monitoring centers, data transmission for long - distance oil and gas pipelines.
5. Installation & Maintenance
Installation Steps
• Mounting: Install the module on a standard DIN rail; ensure stable fixing to prevent vibration - induced loosening.
• Wiring: Connect the 24V DC power supply, Ethernet cables, and fieldbus cables in accordance with the wiring diagram; pay attention to polarity and shielding.
• Protocol Configuration: Set communication parameters (baud rate, address, protocol type) via ABB configuration software to match field devices.
• Redundancy Setup: Configure redundant Ethernet parameters to enable automatic switchover in case of link failure.
Maintenance Tips
• Regular Inspection: Check power indicators and communication status lights monthly to confirm normal operation.
• Cable Check: Inspect cable connections quarterly for looseness or damage; replace aged cables promptly.
• Firmware Update: Update the module firmware via official ABB tools to enhance performance and compatibility.
• Fan Maintenance: For the replacement model PU410K01, clean or replace the fan annually to ensure heat dissipation efficiency.
• ESD Protection: Use anti - static tools when handling the module to avoid electrostatic damage.
Additional Information
PU410
0.00
Sweden
Germany
85389091
Spare_Parts
PU410
0.39 kg
Communication Box
No
1 piece
1 piece
New
Communication Box
0.39 kg
Spare_Parts
No
piece
Wickliffe, Ohio, United States
Product Not in WEEE Scope
Technical Document | ABB PU410 3BSE056478R1 | RTA Communication Box | Advant OCS MB300 Controller
