ABB 5SHX1445H0002 3BHL000387P0101 Asymmetric IGCT Module--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB 5SHX1445H0002 3BHL000387P0101 Asymmetric IGCT Module
High-Power Integrated Gate-Commutated Thyristor for Medium/High Voltage Power Conversion
1. Product Overview
The ABB 5SHX1445H0002 (Ordering Code: 3BHL000387P0101) is an asymmetric Integrated Gate-Commutated Thyristor (IGCT) power module, belonging to ABB's 5SHX series. It is designed for medium and high-voltage power conversion systems, such as high-voltage inverters, large motor drives, and power quality control equipment. With high current handling capacity, fast switching speed, and robust industrial design, this module enables efficient, reliable, and precise control of large electrical loads in harsh industrial environments. It is a core component for high-power applications in power generation, metallurgy, petrochemical, and other heavy industries, ensuring stable operation and energy efficiency optimization of power electronic systems.
2. Key Technical Specifications
• Brand & Model: ABB 5SHX1445H0002 (Ordering Code: 3BHL000387P0101)
• Product Type: Asymmetric IGCT Power Module
• Technology: Integrated Gate-Commutated Thyristor (IGCT)
• Rated Voltage: 3.3 kV AC
• Rated Current: 1445 A RMS
• Power Rating: 3315 kW (at 3.3 kV, 50/60 Hz)
• Switching Frequency: Up to 1 kHz (Typical)
• Turn-Off Capability: Unbuffered Turn-Off, High dv/dt Immunity
• Mounting: Standard Heat Sink Compatible (86×86×25 mm Footprint)
• Protection Class: IP20
• Operating Temperature: -25°C to +70°C (-13°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Isolation Voltage: 6 kV AC (1 min)
• Cooling Method: Forced Air/Water Cooling (Typical Thermal Resistance: 0.08 K/W)
• Weight: Approx. 2.96 kg
• Certification: CE, UL, IEC 60747-10
3. Core Features
• High Power Density: 1445 A current rating at 3.3 kV for compact high-power system design.
• Fast Switching: Unbuffered turn-off capability for medium-frequency (MF) power conversion.
• Robust Reliability: Designed for harsh industrial environments with high thermal and electrical stress tolerance.
• Asymmetric Design: Optimized for rectifier/inverter applications requiring unidirectional current flow.
• Low Losses: Advanced IGCT technology reduces conduction and switching losses, improving energy efficiency.
• Easy Integration: Standard footprint and mounting for seamless system assembly.
• Comprehensive Protection: Overcurrent, overvoltage, and overtemperature protection for system safety.
• Long Service Life: Industrial-grade materials and construction for extended operational lifespan.
4. Typical Applications
• Power Generation: Excitation control for hydro, combined-cycle, and pumped-storage power plants.
• Metallurgy: High-power drives for rolling mills, blast furnaces, and smelting equipment.
• Petrochemical: Medium-voltage motor drives for compressors, pumps, and fans in refineries and chemical plants.
• Mining: Large traction drives and conveyor system power supplies for heavy mining equipment.
• Power Quality: Static Var Compensators (SVC) and Active Front Ends (AFE) for grid stability.
5. Installation & Maintenance
Installation Steps
• Mounting: Attach to a compatible heat sink with even torque; ensure flat contact for optimal heat transfer.
• Electrical Connection: Connect AC power terminals and gate control signals per the wiring diagram; use shielded cables for gate signals.
• Cooling Setup: Install forced air or water cooling system; verify flow and pressure meet module requirements.
• Pre-Commissioning: Check insulation resistance, gate voltage, and thermal resistance before power-up.
Maintenance Tips
• Periodic Inspection: Check terminal tightness and heat sink cleanliness monthly to prevent overheating.
• Gate Driver Check: Test gate signal integrity quarterly to ensure proper switching performance.
• Thermal Management: Monitor cooling system performance; clean filters and heat sinks bi-annually.
• Replacement: Use ESD-safe tools when replacing; match thermal grease and torque specifications.
Technical Document | ABB 5SHX1445H0002 3BHL000387P0101 | Asymmetric IGCT Module | High-Power Industrial Control
