ABB SYMPHONY PLUS SPASI23 Analog Input Module

High - Precision 24 - Channel RTD & Analog Input for Process Control Systems

1. Product Overview

The ABB SYMPHONY PLUS SPASI23 is a high - performance analog input module specifically designed for ABB Symphony Plus distributed control systems (DCS) in power generation, chemical, oil & gas, and other process industries. It is equipped with 24 independent analog input channels, each with a dedicated analog - to - digital converter (ADC), supporting configurable RTD and high - level analog signal input types. Each channel can be independently configured to meet the diverse signal acquisition requirements of industrial sites, realizing the accurate collection of temperature, pressure, flow, liquid level and other key process parameters. It is fully compatible with the Symphony Plus system, can directly replace SPASI03/SPASI13 modules for system upgrade, and ensures stable and reliable data transmission in harsh industrial environments, which is an essential component for the safe and efficient operation of process control systems.

SPASI23 -3(1).png

2. Key Technical Specifications

• Brand & Model: ABB SYMPHONY PLUS SPASI23

• Product Type: 24 - Channel Analog Input Module (Symphony Plus DCS Dedicated)

• Core Function: RTD/High - Level Analog Signal Acquisition, Independent Channel Configuration

• Input Channels: 24 Independent Channels (Each with Dedicated ADC)

• Input Signal Types: RTD (Pt100, Pt1000, Ni100, Ni120, Cu10), Voltage (0-5V, 1-5V, 0-10V), Current (4-20mA, 0-20mA)

• Measurement Accuracy: ±0.05% of Full Scale (Analog), ±0.1°C (RTD, -200°C to +850°C)

• Resolution: 16 - bit ADC for Each Channel

• Isolation: Channel - to - Channel, Channel - to - Ground Isolation (250V AC)

• Communication Interface: Symphony Plus Local Bus (Compatible with IMASI23 Baseplate)

• Power Supply: 5 V DC (Logic), 24 V DC (Field Power)

• Power Consumption: 12 W (Max)

• Protection Class: IP20

• Operating Temperature: 0°C to +55°C (32°F to +131°F)

• Storage Temperature: -40°C to +85°C (-40°F to +185°F)

• Dimensions (W×H×D): 150 × 220 × 35 mm (5.9 × 8.7 × 1.4 in)

• Weight: Approx. 0.35 kg (0.77 lbs)


3. Core Features

• 24 Independent Channels: Each Channel Has a Dedicated ADC for High - Precision Parallel Acquisition.

• Flexible Configuration: Support RTD and Multiple Analog Signal Types, Configurable per Channel.

• High Accuracy & Resolution: 16 - bit ADC and ±0.05% Full - Scale Accuracy Ensure Data Reliability.

• Complete Isolation: Channel - to - Channel and Channel - to - Ground Isolation Reduce Signal Interference.

• Module Compatibility: Direct Replacement for SPASI03/SPASI13 Modules (with Minor Function Code Adjustments).

• Easy System Integration: Compatible with IMASI23 Baseplate and Symphony Plus Local Bus.

• Hot - Swappable: Supports Online Replacement Without System Shutdown (with Proper Procedures).

• Diagnostic Function: Built - in Self - Test and Channel Fault Detection for Quick Troubleshooting.

SPASI23 -2(1).png

4. Typical Applications

• Power Generation: Thermal Power Plant Boiler, Turbine, Generator Parameter Monitoring.

• Chemical Industry: Reactor Temperature, Pressure, Flow, and Liquid Level Data Acquisition.

• Oil & Gas: Refinery Process Control, Pipeline Pressure and Flow Monitoring.

• Petrochemical: Distillation Tower, Catalytic Cracking Unit Parameter Collection.

• Water Treatment: Water Quality Analysis, Flow, and Pressure Monitoring in Water Supply and Drainage Systems.

• Metallurgy: Blast Furnace, Converter, and Rolling Mill Temperature and Pressure Monitoring.

SPASI23 -1(1).png

5. Installation & Maintenance

• Mounting: Install on ABB IMASI23 Baseplate in Symphony Plus Cabinet (DIN Rail Mounting).

• Wiring: Connect Field Signals (RTD/Voltage/Current) and Power Supply According to Terminal Markings.

• Configuration: Set Channel Signal Type, Range, and Alarm Threshold via Symphony Plus Engineering Software.

• Calibration: Automatic Calibration via System Software; Regular Verification with Standard Signal Source.

• Diagnostics: Use System Diagnostic Tools to Check Channel Status, Isolation, and Communication.

• Maintenance: Hot - Swappable for Online Replacement; Regularly Inspect Terminal Blocks for Looseness.

Technical Document | ABB SYMPHONY PLUS SPASI23 | Analog Input Module | Process Control System
