ABB PFEA112-20 3BSE050091R20 Tension Amplifier/Controller--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB PFEA112-20 3BSE050091R20 Tension Amplifier/Controller

High - Precision Tension Measurement & Closed - Loop Control for Web Processing

1. Product Overview

The ABB PFEA112-20 (Order No.: 3BSE050091R20) is a high - precision tension amplifier and controller tailored for web processing industries such as paper, printing, plastic film, metal strip, and cable manufacturing. It can connect 2 load cells (e.g., ABB PFTL/PFCL series) to collect tension signals, and achieve closed - loop tension regulation through built - in high - precision algorithms and PID control. Equipped with Profibus DP communication interface, it can realize digital data transmission with PLCs or upper - level control systems, effectively reducing signal interference and ensuring stable and reliable tension control in the production process. It supports parameter configuration, package angle compensation, and range adjustment, which is an essential component to improve product quality and production efficiency in web processing lines.

PFEA112-20 3BSE050091R20 -4(1).png

2. Key Technical Specifications

• Brand & Model: ABB PFEA112-20 (Order No.: 3BSE050091R20)

• Product Type: Tension Amplifier & Controller (Web Processing Dedicated)

• Core Function: Tension Measurement, Closed - Loop PID Tension Control, Profibus DP Communication

• Load Cell Interface: 2 Channels, Compatible with ABB PFCL/PFTL/PFRL Series Load Cells

• Input Signal: Magnetoelastic Load Cell Signal (Typical 0-20 mV/V)

• Measurement Accuracy: ±0.1% of Full Scale

• Output Interface: 1 x 0-10 V DC Analog Output, 1 x 4-20 mA Analog Output, 1 x Relay Output, Profibus DP V0

• Communication: Profibus DP (Address Configurable), RS - 485 (Modbus RTU Optional)

• Power Supply: 24 V DC (Typical), 12-48 V DC (Range)

• Power Consumption: 120 W (Max), Rated Current 5 A

• Protection Class: IP20 (Standard), IP65 (Optional)

• Operating Temperature: -10°C to +55°C (14°F to +131°F)

• Storage Temperature: -40°C to +70°C (-40°F to +158°F)

• Dimensions (W×H×D): 170 × 105 × 32 mm (6.7 × 4.1 × 1.3 in)

• Weight: Approx. 120 g (0.26 lbs)

PFEA112-20 3BSE050091R20 -3(1).png

3. Core Features

• Dual Load Cell Input: Connect 2 Load Cells for High - Precision Tension Measurement.

• Profibus DP Integration: Digital Data Transmission with PLC/Control System to Reduce Interference.

• PID Closed - Loop Control: Real - time Tension Adjustment for Stable Web Processing.

• Package Angle Compensation: Custom Angle Setting (90°, 180°, etc.) for Automatic Tension Compensation.

• On - site Parameter Configuration: Tension Range, Calibration, and Communication Settings Adjustable.

• Multiple Output Options: Analog, Relay, and Digital Outputs for Flexible System Integration.

• Wide Load Cell Compatibility: Works with ABB PFCL 201, PFTL 101/201, etc. Load Cells.

• Industrial - Grade Reliability: Suitable for Harsh Industrial Environments with Wide Temperature Range.

PFEA112-20 3BSE050091R20 -1(1).jpg

4. Typical Applications

• Paper & Pulp: Paper Machine Winding, Slitting, and Coating Lines.

• Printing: Flexographic, Gravure, and Offset Printing Press Tension Control.

• Plastic Film: Extrusion, Laminating, and Rewinding Processes.

• Metal Strip: Steel/Aluminum Strip Rolling, Annealing, and Slitting Lines.

• Cable Manufacturing: Wire Drawing, Stranding, and Cable Coiling Tension Regulation.

• Textile: Fabric Weaving, Dyeing, and Finishing Tension Management.

PFEA112-20 3BSE050091R20 -2(1).png

5. Installation & Maintenance

• Mounting: DIN Rail or Panel Mounting in Control Cabinet (IP20) or Field (IP65).

• Wiring: Connect Load Cells, Analog Outputs, Relay, Profibus DP, and Power Supply.

• Configuration: Set Parameters (Tension Range, Package Angle, Communication Address) via ABB Control Panel or Software.

• Calibration: On - site Calibration with Standard Weights or Signal Simulator.

• Diagnostics: LED Indicators for Power, Communication, and Fault Status.

• Maintenance: Regularly Inspect Wiring Harnesses; Clean Air Vents for Heat Dissipation.

Technical Document | ABB PFEA112-20 3BSE050091R20 | Tension Amplifier | Web Processing Control
