- Part number：PFSK151 3BSE018876R1
- Product Origin：Sweden
- HS CODE：8708299000
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
ABB PFSK151 (3BSE018876R1) Communication Interface Module for Industrial Control Systems
Product Description
The ABB PFSK151 (Part Number: 3BSE018876R1) is a high-performance communication interface module engineered for seamless integration between ABB industrial control systems (including AC 800M, System 800xA, and Freelance AC 700F) and third-party devices/networks. As a multi-protocol gateway module, it supports PROFIBUS DP V1 (master/slave), Modbus RTU/TCP, and Ethernet/IP, enabling bidirectional data exchange between distributed I/O modules, PLCs, HMIs, and enterprise-level systems. Featuring redundant communication ports, galvanic isolation, and built-in diagnostics, the PFSK151 ensures reliable, high-speed data transmission (up to 12 Mbps for PROFIBUS) in harsh industrial environments, making it ideal for process control, manufacturing automation, and power distribution applications.
Key Functions
The PFSK151 communication interface module delivers flexible, reliable data exchange for industrial control networks. Key functions include: Multi-protocol support (PROFIBUS DP V1, Modbus RTU/TCP, Ethernet/IP) for cross-system compatibility; dual PROFIBUS ports (redundant) with 12 Mbps maximum baud rate (master/slave configurable); 2x 10/100 Mbps Ethernet ports (RJ45) for Modbus TCP/Ethernet/IP communication; galvanic isolation (2500 VAC) between communication ports and power supply to eliminate ground loops and EMI; built-in diagnostic tools (port status, error logging, network traffic monitoring) with LED indicators and remote access; seamless integration with ABB Control Builder M software for configuration and maintenance; and compliance with IEC 61131-3, IEC 61508 (SIL 2) for safety-critical applications. The module also supports hot-swappable installation for online maintenance without system downtime.
Application Scenarios
The ABB PFSK151 communication interface module is deployed in industrial control networks across process manufacturing, power generation, and discrete automation sectors. In chemical/petrochemical plants, it connects ABB 800xA DCS with third-party flow meters, pressure transmitters, and safety instrumented systems (SIS) via PROFIBUS/Modbus. For power generation facilities, it integrates turbine/generator control systems with SCADA networks using Ethernet/IP, enabling real-time data monitoring and remote control. In automotive/manufacturing plants, it bridges ABB PLCs with production line HMIs, robotic systems, and MES (Manufacturing Execution Systems) for end-to-end process visibility. The module is also suitable for water/wastewater treatment plants and mining operations—all scenarios requiring interoperability between diverse industrial control devices and networks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Multi-Protocol Communication Interface Module |
| Manufacturer | ABB |
| Model/Part Number | PFSK151 / 3BSE018876R1 |
| Supported Protocols | PROFIBUS DP V1 (Master/Slave), Modbus RTU/TCP, Ethernet/IP |
| PROFIBUS Specifications | 2x Redundant Ports; Baud Rate: 9.6 kbps - 12 Mbps; RS-485 Physical Layer |
| Ethernet Specifications | 2x 10/100 Mbps RJ45 Ports; Full/Half Duplex; Auto-MDI/MDIX |
| Isolation | Galvanic Isolation (2500 VAC) - Communication Ports to Power Supply/Logic |
| Power Supply | 24 VDC (18-30 VDC Range); Redundant Power Input; Max Power Consumption 8 W |
| Diagnostics | LED Indicators (Power, PROFIBUS Status, Ethernet Status, Fault); Error Logging; Remote Diagnostics via ABB Control Builder M |
| Operating Environment | Temperature: 0°C to 55°C (Operating); -20°C to 70°C (Storage); Humidity: 5-95% RH (Non-Condensing); Vibration: 5-500 Hz, 2 g RMS |
| Certifications & Standards | IEC 61131-3, IEC 61508 SIL 2, CE, UL, CSA, ATEX, IECEx Approved |
| Mechanical Features | DIN Rail Mountable (35 mm); Hot-Swappable; Plug-In Terminal Blocks; Dimensions: 120 x 100 x 60 mm (WxHxD) |
| Compatibility | ABB AC 800M, System 800xA, Freelance AC 700F, ABB S800 I/O Modules |
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
