ABB 5SHX08F4502 3BHB003387R0101 IGCT Module
Product Description
The ABB 5SHX08F4502 3BHB003387R0101 is an advanced Integrated Gate Commutated Thyristor (IGCT) module, a high-power electronic switching device designed for high-voltage and high-current power conversion and control systems. Combining the advantages of IGBT and GTO technologies, this module integrates an IGCT chip, anti-parallel diode, and gate drive circuit in a compact, low-inductance structure, enabling efficient and stable energy conversion with reduced power losses. It features robust construction, excellent thermal stability, and easy installation, making it suitable for harsh industrial environments while ensuring reliable long-term operation for critical power applications.
Key Functions
The 5SHX08F4502 3BHB003387R0101 serves as a core switching component for high-power energy conversion, enabling precise control of large electrical currents in power systems with a base switching frequency around 500 Hz and short pulse capabilities up to 40 kHz (limited by thermal management). It provides integrated protection functions including overcurrent, overvoltage, and overtemperature protection to safeguard the module and connected equipment from damage. The module’s low power consumption (10-100W control power) and efficient heat dissipation ensure stable performance under high-load conditions, while its compact, integrated design simplifies system integration and reduces overall installation complexity.
Application Scenarios
This IGCT module is widely utilized in power-intensive industrial and energy systems, including renewable energy installations (solar and wind power plants) for power conversion and grid integration, industrial motor drives and large-scale frequency converters, power transmission and distribution networks for voltage stabilization, railway traction systems, and high-power inverters and converters in industrial automation. It is also suitable for uninterruptible power supply (UPS) systems and electrical grid stabilization projects where high reliability and efficient power control are critical.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Integrated Gate Commutated Thyristor (IGCT) Module |
| Control Power Consumption | 10-100 W |
| Switching Frequency | Base: ~500 Hz; Short pulse capability: up to 40 kHz |
| Integrated Components | IGCT chip, anti-parallel diode, gate drive circuit |
| Protection Features | Overcurrent, overvoltage, overtemperature protection |
| Operating Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Mechanical Life | 10,000 cycles |
| Certifications | CE, RoHS |
