ABB MT91-ARC (MT-91-ARC FP A) 12.1-inch Procontic CS31 Operator Panel--KIMI
  • Warehouse: Spot
  • Warranty: 365 days
  • Quality: Original module
  • Condition: New
  • Shipping method: Courier delivery

  • Contact person: LI MING
  • Contact number: +86 18059884790
  • WeChat:18059884790
  • E-mail: plc66@qq.com

Product Description


ABB MT91-ARC (MT-91-ARC FP A) 12.1-inch Procontic CS31 Operator Panel
HMI for Robot Programming, Industrial Control & Maintenance Monitoring
1. Product Overview

The ABB MT91-ARC (full model: MT-91-ARC FP A) is a 12.1-inch operator panel from the Procontic CS31 series, specialized for human-machine interaction in ABB robot control and industrial automation systems. It features a 12.1" TFT color LCD touch screen, delivering clear visualization and intuitive operation for robot programming, motion control, real-time status monitoring, and fault diagnostics. Equipped with 2 serial ports, 2 USB ports, and Ethernet connectivity, it seamlessly integrates with industrial control networks, supporting multi-language display and various programming languages (e.g., Ladder Logic, Structured Text). With a 100-240VAC power supply and robust construction, it operates reliably in harsh industrial environments, enhancing operational efficiency and simplifying maintenance in manufacturing, power, chemical, and automotive industries.


MT91-ARC (4).jpg


2. Key Technical Specifications
• Brand & Model: ABB MT91-ARC (MT-91-ARC FP A)
• Product Type: 12.1-inch Operator Panel (Procontic CS31 Series)
• Display: 12.1" TFT Color LCD Touch Screen, 800×600 Pixels
• Processor: Procontic CS31 Embedded Controller
• Interfaces: 2×Serial (RS-232/485), 2×USB, 1×Ethernet (RJ45)
• Power Supply: 100-240VAC, 50/60Hz
• Protection Rating: IP65 Front, IP20 Rear
• Operating Temperature: 0°C to +50°C (32°F to +122°F)
• Dimensions: 32.0 cm × 24.0 cm × 8.5 cm (12.6" × 9.45" × 3.35")
• Weight: Approx. 2.2 kg (4.85 lb)
• Software: Procontic CS31 OS, Multi-Language Support
• Programming Support: Ladder Logic, Structured Text, Function Block Diagram

• Certifications: CE, UL, RoHS


MT91-ARC (1).jpg


3. Core Features
• Intuitive HMI: 12.1" color touch screen for clear visualization of robot motion and process data.
• Versatile Connectivity: Serial, USB, and Ethernet for seamless integration with control systems.
• Multi-Language Support: Adapts to global industrial environments with multi-language UI.
• Robust Construction: IP65 front protection resists dust and water ingress.
• Flexible Programming: Supports standard industrial programming languages for custom control.
• Real-Time Monitoring: Tracks robot status, process parameters, and fault alarms.

• Easy Maintenance: Built-in diagnostics for quick troubleshooting and system recovery.


MT91-ARC (3).jpg


4. Typical Applications
• Robot Control: Programming, teaching, and motion control for ABB industrial robots.
• Manufacturing Lines: Monitoring and control of assembly, welding, and material handling systems.
• Power & Utilities: Control and diagnostics of switchgear, breakers, and power distribution systems.
• Process Industries: HMI for DCS/PLC-based control in chemical, petrochemical, and pharmaceutical plants.

• Automotive Production: Programming and monitoring of robotic welding, painting, and assembly cells.


MT91-ARC (2).jpg


5. Installation & Maintenance
Installation Steps
• Mounting: Panel-mount using standard cutout; ensure proper ventilation and clearance.
• Wiring: Connect AC power (100-240VAC) and communication cables (Ethernet/serial).
• Configuration: Set network parameters and load Procontic CS31 applications via USB/Ethernet.

• Testing: Verify touch response, communication links, and robot control functionality.


MT91-ARC (1)(1).jpg

Maintenance Tips
• Daily: Wipe front screen with a soft, lint-free cloth to remove dust/debris.
• Weekly: Inspect cables/connectors for damage or loose connections.
• Monthly: Check power supply voltage and ensure proper enclosure ventilation.
• Quarterly: Update firmware and back up configuration data to a USB drive.
• Annually: Calibrate touch screen and perform full system diagnostics.
Technical Document | ABB MT91-ARC (MT-91-ARC FP A) | 12.1-inch Operator Panel | Robot & Industrial Control
