The GE DS200TCCAG1BAA is a TC2000 common analog I/O board engineered for seamless integration with GE Speedtronic Mark V turbine control systems, delivering precise analog signal acquisition and output for critical turbine monitoring and control applications. At its core is an 80196 microprocessor paired with programmable PROM modules for firmware storage, enabling high-speed processing of analog inputs (temperature, pressure, flow) and generation of control outputs (4-20mA, ±10V) for actuators and valves. This board features 8 differential analog input channels (16-bit resolution, 0.1% accuracy) and 4 analog output channels (16-bit DAC, 0.1% full-scale precision), with electrical isolation between channels to prevent cross-interference and ensure measurement integrity. It integrates advanced signal conditioning, including filtering and linearization, to handle noisy industrial environments, while a side-mounted LED provides visual status indication for power, communication, and channel faults. With dual 50-pin connectors (JCC/JDD) for backplane and field wiring, the DS200TCCAG1BAA ensures reliable connectivity to Mark V I/O modules and sensors, making it ideal for utility power plants, combined-cycle facilities, and industrial turbine systems requiring accurate analog control and fault tolerance.
