GE H201Ti Hydran 201Ti On-line DGA Transmitter
Continuous Dissolved Gas-in-Oil Analysis for Transformer Fault Early Warning
1. Product Overview
The GE H201Ti (Hydran 201Ti) is a compact, easy-to-install continuous Dissolved Gas-in-Oil Analysis (DGA) transmitter permanently mounted on transformers. Utilizing fuel cell-based composite gas sensor technology, it delivers the world-renowned "Hydran gas value," responding 100% to Hydrogen (general fault gas) and sensitive to Carbon Monoxide (overheated paper), Acetylene (arcing), and Ethylene (overheated oil) — covering all main transformer failure root causes. With Dynamic Oil Sampling, it eliminates the need for pumps or extra piping, offering real-time monitoring, local/remote alarms, and Modbus communication for seamless integration into power monitoring networks, ensuring early fault detection and minimizing unplanned outages.
Key Specifications
• Model: H201Ti (Hydran 201Ti) | Brand: GE Vernova | Series: Hydran 201i Monitoring System
• Type: On-line DGA Transmitter for Transformer Health Monitoring
• Sensor Technology: Fuel cell composite gas sensor (gas-permeable membrane)
• Measured Gases: H₂ (100% response), CO, C₂H₂, C₂H₄ (fault-specific gases)
• Measurement Range: 0-2000 ppm (Hydran gas value); Accuracy: ±2 ppm
• Sampling Method: Dynamic Oil Sampling (no pumps/piping required)
• Communication: RS-485 (Modbus RTU protocol); Optional RS-232
• Alarms: Local (LCD) and remote (SPDT contacts), settable on level/rate-of-change
• Display: LCD (local gas value, status, alarms)
• Power Supply: 24 VDC (18-32 V range); Power Consumption: ~3 W
• Mounting: Single transformer valve (brass adapter included)
• Operating Temperature: -20°C to +60°C; Storage: -40°C to +85°C
• Humidity: 5-95% (non-condensing); Protection: IP65 (external housing)
• Certifications: CE, UL, RoHS; Compliance: IEEE C57.104
• Dimensions: 150 mm × 120 mm × 80 mm; Weight: 0.8 kg
• Compatibility: H201Ci-1 Controller, SCADA, Power Monitoring Systems
2. Core Features
• Fuel Cell Sensor: Industry-proven "Hydran gas value" for reliable fault gas detection
• No Moving Parts: Maintenance-free design with no pumps or consumables
• Plug-and-Play Installation: Mounts on single valve; no extra piping needed
• Local & Remote Alarms: Settable thresholds for early fault warning
• Data Logging: 1-year local storage of gas values and events
• Modbus Integration: Seamless connection to SCADA/H201Ci-1
• IP65 Protection: Dust/waterproof for outdoor substation environments
• Low Power: 3 W operation for energy efficiency
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Power Transformers: Distribution/transmission transformers (medium/large fleets)
• Substations: Grid infrastructure for early fault detection
• Industrial Transformers: Petrochemical, mining, manufacturing plants
• Railway Traction: Railway power supply transformers
• Renewable Energy: Wind/solar farm transformers
4. Installation & Maintenance
Installation: Mount on transformer valve (brass adapter); Connect 24 VDC power; Wire RS-485 (Modbus); Set alarms via LCD/controller.
Maintenance: No field calibration; Annual visual inspection (connections/housing); Replace sensor every 5-7 years (per GE recommendation).
Safety: De-energize before installation; Use ESD protection; Follow IEEE C57.104 guidelines.
