H201Ci-1 Hydran 201Ci-1 Single Channel Controller--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
GE H201Ci-1 Hydran 201Ci-1 Single - Channel Controller
Single - Channel Controller for Hydran 201Ti Transmitter, Transformer Dissolved Gas Analysis (DGA) Monitoring
1. Product Overview
The GE H201Ci-1 (Hydran 201Ci-1) is a single - channel controller specially designed for the Hydran 201i on - line dissolved gas monitoring system. When paired with the Hydran 201Ti intelligent transmitter, it forms the Hydran 201R Model i Incipient Fault Monitor, which can continuously monitor the concentration of combustible gases dissolved in transformer oil (such as hydrogen, carbon monoxide, ethylene, acetylene, etc.). It provides precise measurement data, multi - level alarm functions and flexible analog output, enabling early warning of potential faults in oil - filled electrical equipment, thus ensuring the safe and stable operation of power equipment. With a NEMA 4X cabinet and a wide temperature - resistant design, it is very suitable for harsh outdoor and industrial substation environments.
Key Specifications
• Model: H201Ci-1 (Hydran 201Ci-1) | Brand: GE | Series: Hydran 201i Monitoring System
• Type: Single - Channel Controller for Transformer DGA Monitoring
• Working Principle: Cooperates with Hydran 201Ti to monitor dissolved combustible gases in oil
• Measurable Gases: H₂, CO, C₂H₄, C₂H₂, etc. (combustible gases dissolved in transformer oil)
• Analog Output: 0-1 mA, 4-20 mA, 0-1 V, 0-10 V (configurable by jumper), measurement range 0-2000 ppm
• Alarm Function: High gas level alarm, high - high gas level alarm, fault alarm (SPDT C - type contact)
• Communication Interface: RS - 232, RS - 485 (supports Modbus protocol)
• Power Supply: 24 VDC (18-32 V range), Power Consumption: ~ 4 W
• Cabinet Protection: NEMA 4X (heated cabinet, suitable for outdoor low - temperature environment)
• Indicators: Power (Green), Alarm (Red), Communication Status (Amber), Fault (Red)
• Operating Temperature: -20°C to +60°C; Storage Temperature: -40°C to +85°C
• Humidity: 5% - 95% (non - condensing)
• Certifications: CE, UL, RoHS Compliant
• Dimensions: 250 mm (W) × 180 mm (H) × 120 mm (D); Weight: 1.2 kg
• Compatibility: Special match with Hydran 201Ti intelligent transmitter
2. Core Features
• Single - Channel Precision Monitoring: Specifically designed for Hydran 201Ti to achieve accurate measurement of dissolved gases in oil
• Multi - type Output Configuration: Multiple analog output modes are available to adapt to different monitoring systems
• Multi - level Alarm Mechanism: Timely alert of potential faults in transformers to ensure the safety of power equipment
• Flexible Communication: Supports RS - 232/RS - 485 and Modbus protocol for easy integration into the power monitoring network
• Harsh Environment Adaptability: NEMA 4X heated cabinet can work stably in outdoor low - temperature and harsh environments
• Simple Maintenance: Single circuit board design makes maintenance and component replacement convenient and fast
• Energy - saving and Environmental Protection: Low power consumption of about 4 W, which is energy - saving and cost - effective
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Power Industry: Online monitoring of power transformers in substations and power plants to detect incipient faults in advance
• Petroleum and Chemical Industry: Monitoring of oil - filled electrical equipment in petrochemical plants, such as transformers and reactors
• Railway Power Supply: Monitoring of traction transformers in railway systems to ensure the reliable operation of railway power supply
• Industrial and Mining Enterprises: Monitoring of oil - filled electrical equipment in large - scale industrial and mining enterprises to avoid equipment damage caused by faults
• Renewable Energy: Monitoring of transformers in wind farms and solar power stations to improve the operation efficiency of new energy equipment
4. Installation & Maintenance
Installation: Wall - mounted or panel - mounted installation; Connect 24 VDC power supply; Wire analog output and communication interface (RS - 232/RS - 485); Configure output mode by jumper; Match with Hydran 201Ti intelligent transmitter for system debugging.
Maintenance: Daily - Check indicator lights (Power, Alarm, Communication, Fault); Weekly - Verify data consistency and communication stability; Annual - Inspect wiring, clean the cabinet, and update the device program if necessary.
Safety Notes: Use an ESD wrist strap during operation; Cut off the power supply before replacing components; Follow the relevant safety specifications of the power industry during installation and maintenance.
Technical Document | H201Ci-1 | Hydran 201Ci-1 Single - Channel Controller
