1. Product Overview
The GE IS420UCSCH2A-C-V0.1-A is a hardware version (V0.1-A) of the high-performance dual-core UCSC (Unified Control System Controller) module, engineered as the core processing unit of GE Speedtronic Mark VIe Distributed Control System (DCS) for mission-critical industrial power generation and turbine control. This version features a 1.2 GHz dual-core industrial CPU optimized for V0.1 firmware, 2GB DDR3 SDRAM, 4GB bootable flash memory, and QNX Neutrino Real-Time Operating System (RTOS) for deterministic control logic execution. It supports simplex, dual, and triple modular redundant (TMR) architectures, with dual Gigabit Ethernet ports for IONet/plant network redundancy, ensuring zero-downtime operation in gas/steam turbine, hydroelectric, and oil & gas processing applications. With a -40°C to +70°C operating range, SIL 3 capability (IEC 61508), and rugged industrial design, it delivers reliable 24/7 performance in harsh control environments.
Key Specifications (V0.1-A Version)
• Model: IS420UCSCH2A-C-V0.1-A | Brand: GE | Series: Mark VIe Speedtronic
• Type: Dual-Core UCSC Controller Module (Hardware Version V0.1-A)
• Processor: 1.2 GHz Dual-Core Industrial CPU (V0.1 Optimized); L2 Cache: 4MB
• Memory: 2GB DDR3 SDRAM (ECC); 4GB Industrial-Grade Flash (Bootable)
• OS: QNX Neutrino RTOS (V0.1 Firmware Compatible)
• Communication: Dual Gigabit Ethernet (RJ-45) – IONet (Redundant) + Plant Network
• Redundancy: Simplex/Dual/Triple Modular Redundant (TMR) Configurations Supported
• Power Supply: 24V DC (18-32V DC Range); 3-Pin Locking Connector; Max Power: 7.5W
• Environmental: Operating -40°C to +70°C; Storage -55°C to +85°C; Humidity 5-95% (Non-Condensing)
• Mechanical: 114mm (H) × 229mm (W) × 38mm (D); 0.54kg; DIN-Rail/Chassis Mount
• Certifications: CE, UL 508, IEC 61326-1, SIL 3 Capable (IEC 61508)
2. Core Features (V0.1-A Version)
• V0.1-A Hardware Optimization: Tailored for early Mark VIe V0.1 firmware, ensuring stable compatibility with legacy systems
• Dual-Core Parallel Processing: 1.2 GHz CPU enables simultaneous execution of control logic and data acquisition (10μs response time)
• Redundant Gigabit Ethernet: Dual ports for IONet redundancy – automatic failover (<50ms) to prevent communication loss
• TMR Compatibility: Supports triple modular redundancy for fault-tolerant control in nuclear/hydro power applications
• ECC Memory Protection: Error-Correcting Code (ECC) DDR3 prevents data corruption in harsh industrial environments
• Hot-Swappable Design: Online replacement in redundant setups – no system shutdown required
• QNX RTOS Determinism: V0.1 firmware-tuned real-time performance for time-critical turbine control tasks
• Ruggedized Construction: Conformal coating option for dust/humidity/vibration resistance (per IEC 60068-2)
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
Sales Manager: KI MI
WeChat: 18059884790
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Power Generation: Gas/Steam Turbine Control (Mark VIe V0.1 Systems), Hydroelectric Plant DCS
• Oil & Gas: Offshore Platform Turbine Control, Pipeline Compressor Systems, FPSO Power Management
• Industrial Turbines: Cogeneration Plants, Combined Cycle Power Systems (CCPP)
• Critical Infrastructure: Nuclear Power Plant Auxiliary Control (SIL 3 Compliant Configurations)
• Marine: Shipboard Propulsion Turbine Control (Mark VIe Marine V0.1 Deployments)
4. Installation & Maintenance (V0.1-A Version)
Installation: Mount in Mark VIe I/O Chassis; Connect 24V DC locked power connector; Configure dual Ethernet (IP/subnet for V0.1 firmware); Verify LED status (Power: Green, Comms: Blue, Fault: Red).
Maintenance: Weekly – Check LED indicators & Ethernet link integrity; Monthly – Validate V0.1 firmware compatibility via ToolboxST; Annual – Inspect conformal coating (if fitted), update firmware (only to V0.1-compatible revisions).
Safety Notes: De-energize chassis before non-hot-swap maintenance; Use ESD protection; Follow GE Mark VIe V0.1 safety guidelines; Isolate high-voltage circuits from controller wiring.
