F-PWR01 F-PWR02 HIQuad X Power Supply Module
The HIMA F-PWR02 is a power buffer module used in the HIMA safety Instrumented system (SIS), and is particularly common in the HIMA HIQuad X system. Its main function is to provide a stable 24VDC power supply for the I/O processing module in the system and it has the ability to buffer voltage fluctuations.
Main functions and features
Power buffering and distribution: The core function of the F-PWR02 is to ensure that the connected I/O modules receive a stable and continuous 24VDC power supply. Even if the main power supply experiences a short-term interruption (for example, up to 20 ms), the F-PWR02 can maintain the power supply through its buffering capacity and prevent system interruption. This is crucial for maintaining the continuous operation of the security system.
Voltage fluctuation compensation: It can effectively compensate for voltage fluctuations, ensuring that the I/O module can still operate reliably in environments with poor power quality or transient voltage drops.
Redundant power supply support: The F-PWR02 can be used in conjunction with redundant power supply units to further enhance the power supply reliability of the system. This means that even if one power unit fails, the other can take over to ensure seamless power supply.
System Integration: As part of the HIQuad X system, the F-PWR02 is designed to seamlessly collaborate with other modules of HIMA, such as the F-CPU01 processor module and various I/O modules.
Safety-related applications: As it supplies power to critical I/O modules in security systems, the F-PWR02 is also designed to adhere to high safety standards, ensuring that it itself does not become the source of system failures.
Diagnosis and Signals: Generally, the power module of HIMA provides diagnostic information or relay contacts to indicate the power status, facilitating system monitoring and fault detection.
Overview Modules
| HIQuad X | |
|---|---|
| F-CPU 01 | Processor module H51X, H41X (2x RJ-45, SIL 3) |
| F-COM 01 | Communication module for Ethernet, Profibus DP and serial communication (2x RJ-45, 1 x 9-pole D-SUB 2x RS 485) |
| F-BASE RACK 01 | Base rack H51X, 19 inches, 4 units high |
| F-BASE RACK 01 R | Base rack H51X, rugged subrack 19 inches, 4 units high |
| F-BASE RACK 02 | Base rack H41X, 19 inches, 4 units high, 12 slots for I/O modules |
| F-BASE RACK 02 R | Base rack H41X, rugged subrack 19 inches, 4 units high, 12 slots for I/O modules |
| F-BASE RACK 11 | Extention rack H41X/H51X, H51q, 19 inches, 4 units high, 16 slots for I/O modules |
| F-BASE RACK 12 | Extension rack H41X, H51X, 19 inches, 4 units high, 16 slots for I/O modules |
| F-BASE RACK 12 R | Extension rack H41X, H51X, rugged subrack 19 inches, 4 units high, 16 slots for I/O modules |
| F-PWR 01 | Power supply module 24 VDC / 5 VDC, 50W, H41X, H51X |
| F-PWR 02 | Watchdog supply module for extension rack, H51X |
| F-IOP 01 | I/O processing module (SIL 3) with redundant system bus |
| F-FAN 01 | System fan for racks, 19 inches, 1 unit high |
| I/O modules | SIL | Channels | SC/OC | Ex | Note |
|---|---|---|---|---|---|
| Input modules digital | |||||
| F 321 | 16 | - | - | Contacts, 1 signal 24 VDC | |
| F3224A | 4 | - | yes | Contacts, 1 signal, SN-, proximity switches, wired contacts, ATEX | |
| F 3236 | 3 | 16 | - | - | Contacts, 1 signal 24 VDC |
| F 3240 | 3 | 16 | - | - | Contacts, 1 signal 110 VDC/127 VAC |
| F 3248 | 3 | 16 | - | - | Contacts, 1 signal 48 VDC |
| Input modules Initiator | |||||
| F 3237 | 3 | 8 | yes | - | SN-, proximity switches, wired contacts |
| F 3238 | 3 | 8 | yes | yes | SN-, proximity switches, wired contacts, 8 DU wide, ATEX |
| Input modules analog | |||||
| F 6215 | 0 | 8 | yes | - | Current, voltage, Pt100 |
| F 6217 | 3 | 8 | yes | - | Current, voltage |
| F 6221 | 3 | 8 | yes | yes | Current, voltage, ATEX |
| Output modules digital | |||||
| F 3322 | 16 | - | - | 24 VDC to 0.5 A | |
| F 3325 | 3 | 6 | - | yes | Ex transmitter supply module for F 6221, ATEX |
| F 3330 | 3 | 8 | - | - | 24 VDC to 0.5 A |
| F 3331 | 3 | 8 | yes | - | 24 VDC to 0.5 A |
| F 3333 | 3 | 4 | - | - | 24 VDC to 2 A |
| F 3334 | 3 | 4 | yes | - | 24 VDC to 2 A |
| F 3335 | 3 | 4 | - | yes | 24 VDC, ATEX |
| F 3349 | 3 | 8 | yes | - | 24 VDC/48 V DC to 0.5 A |
| F 3422 | 8 | - | - | Relay module, 30 VAC/DC, 120 W, floating NO contact | |
| F 3430 | 3 | 4 | - | - | Relay module, 110 VDC/250 V AC to 4 A |
| Output modules analog | |||||
| F 6705 | 3 | 2 | - | - | Current |
| F 6706 | 2 | - | - | Current | |
| Special modules | |||||
| F 5220 | 3 | 2 | yes | - | Counter module initiator, 5 VDC, 24 V DC to 1 MHz, 2 integral digital outputs 24 VDC to 0.5 A |
| * in conjunction with safety-related protocol | |||||
| Terminal modules | |||||
| H 7015A | Terminal Module with Vario plug ELCO 8016 (Code 1-1). For wiring to e.g. H 7016, H 7018. | ||||
| H 7018 | Terminal Module with Vario plug ELCO 8016 (Code 1-1). For wiring to H 7015(A). | ||||
| H 7020 | Terminal Module for connection between I/O modules and the field level | ||||
